Saab 9-2X I (2004-2006) rear defogger (at lower right corner Wiring diagram
This page shows the only wiring diagram for the component.rear defogger (at lower right corner, which is found in the car Saab 9-2X I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear defogger (at lower right corner (1 of 1)
2.0L TURBO 2.5L
AUTO A/C CONTROL MODULE (BELOW CENTER OF DASH)
AUTOMATIC A/C MANUAL A/C
BLK WIRE
BLK/YEL WIRE
BLU WIRE
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
FUSE 11
FUSE 19
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-6 (UNDER LEFT FRONT OF CENTER CONSOLE)
GB-8 (UNDER RIGHT TAILGATE ASSEMBLY)
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION SWITCH
INTEGRATED MODULE (BEHIND LEFT SIDE OF DASH)
INTERIOR LIGHTS SYSTEM GB-5 (BEHIND CENTER OF DASH)
LEFT REARVIEW MIRROR
MAIN FUSE BOX (M/B) (ON LEFT SIDE OF ENGINE COMPT) FUSE 1
MIRROR HEATER
MIRROR HEATER RELAY (BEHIND LEFT SIDE OF DASH, IN RELAY BLOCK)
NCA WIRE
ON LOCK OFF
ORG/WHT WIRE
REAR DEFOGGER (AT LOWER RIGHT CORNER
REAR DEFOGGER RELAY
REAR DEFOGGER SWITCH
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT REARVIEW MIRROR
VIO WIRE
Go to component -> Rear defogger circuit -> REAR DEFOGGER (AT LOWER RIGHT CORNER
