Saab 9-2X I (2004-2006) passenger side rearview mirror heater Wiring diagram
This page shows the only wiring diagram for the component.passenger side rearview mirror heater, which is found in the car Saab 9-2X I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side rearview mirror heater (1 of 1)
AIR BAG CONTROL MODULE
BLK WIRE
BLK/WHT WIRE
BLOWER FAN SWITCH
COMPASS MIRROR
EARTH BRACKET RADIO
FAN CONTROL AMPLIFIER
FROM GROUND GB-4 (DIAGRAM 1 OF 3)
FRONT SEAT)
FUEL PUMP ASSEMBLY (2.5L)
FUEL PUMP CONTROLLER (2.0L TURBO)
GB-4 (BEHIND RIGHT SIDE OF DASH)
GB-5 (BEHIND CENTER OF DASH)
GB-6 (UNDER LEFT FRONT OF CENTER CONSOLE)
GB-7 (UNDER RIGHT
GB-8 (UNDER RIGHT TAILLIGHT ASSEMBLY)
GR (UNDER RIGHT FRONT OF CENTER CONSOLE)
LEFT REAR COMBINATION COMBINATION LIGHT
LEFT REAR DOOR SWITCH
LEFT SEAT HEATER
LEFT SEAT HEATER SWITCH
LICENSE PLATE LIGHT
LIGHT
PASSENGER SIDE REARVIEW MIRROR HEATER
REAR ACCESSORY POWER SUPPLY SOCKET
REAR DEFOGGER
REAR GATE LATCH SWITCH HIGH- MOUNTED STOP
REAR WIPER INTERMITTENT MODULE
REAR WIPER MOTOR
RIGHT REAR COMBINATION LIGHT
RIGHT REAR DOOR SWITCH
RIGHT SEAT HEATER
RIGHT SEAT HEATER SWITCH
ROOM LIGHT PASSENGER SIDE DOOR LOCK SWITCH
SEAT BELT SWITCH
SPOT LIGHT
TRAILER CONNECTOR
Go to component -> Ground distribution circuit (2 of 3) -> PASSENGER SIDE REARVIEW MIRROR HEATER
