Saab 9-2X I (2004-2006) mist off hi off mist switch int lo Wiring diagram
This page shows the only wiring diagram for the component.mist off hi off mist switch int lo, which is found in the car Saab 9-2X I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mist off hi off mist switch int lo (1 of 1)
BLK WIRE
BLK/BLU WIRE
COMBINATION SWITCH
FRONT WASHER MOTOR (AT LEFT FRONT OF ENGINE COMPT)
FRONT WIPER MOTOR (AT LEFT REAR OF ENGINE COMPT)
GB-3 GB-4 (BEHIND RIGHT SIDE OF DASH)
GRN/YEL WIRE
HI OFF
HOT IN ACC OR ON FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) FUSE 15
INT (VOLUME)
INTERMITTENT WIPER MODULE
LT GRN/RED WIRE
MIST OFF HI OFF MIST SWITCH INT LO
NCA WIRE
OFF
OFF HI INT LO LO
PARK
REAR WIPER CIRCUIT
RED/BLU WIRE
RUN WIRE
WASHER SWITCH
WIPER MOTOR
WIPER SWITCH
YEL WIRE
YEL/BLK WIRE
Go to component -> Front wiper/washer circuit -> MIST OFF HI OFF MIST SWITCH INT LO
