Saab 9-2X I (2004-2006) left turn signal ind light Wiring diagram
This page shows the only wiring diagram for the component.left turn signal ind light, which is found in the car Saab 9-2X I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left turn signal ind light (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/RED WIRE
COMBINATION SWITCH
FUSE 16
FUSE 2
FUSE 5
FUSE 6
FUSE 7
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) FUSE 5
GB-1 (RIGHT REAR OF ENGINE)
GB-3
GB-5 (BEHIND CENTER OF DASH)
GB-8 (UNDER RIGHT TAILLIGHT ASSEMBLY)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HAZARD SWITCH
HEAD
HIGH MOUNTED STOPLIGHT
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY (BEHIND LEFT SIDE OF DASH, IN RELAY BLOCK)
KEYLESS ENTRY CONTROL MODULE (BEHIND LEFT END OF DASH)
LEFT FRONT COMBINATION LIGHT
LEFT FRONT TURN SIGNAL LIGHT LEFT FRONT CLEARANCE LIGHT
LEFT REAR COMBINATION LAMP
LEFT TURN SIGNAL IND LIGHT
LICENSE PLATE LIGHT
LIGHTING SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
MAIN FUSE BOX (M/B) (ON LEFT SIDE OF ENGINE COMPT)
NCA WIRE
OFF
OFF ON OFF PARK
ON OFF
ON OFF OFF
ORG/ WIRE
PARKING SWITCH
RED WIRE
RED/YEL WIRE
RIGHT FRONT COMBINATION LIGHT COMBINATION METER
RIGHT FRONT TURN SIGNAL LIGHT RIGHT FRONT CLEARANCE LIGHT
RIGHT REAR COMBINATION LAMP
RIGHT TURN SIGNAL IND LIGHT
SBF-2 FUSE
STOP LIGHT
STOPLIGHT SWITCH
TAIL LIGHT STOP LIGHT
TAIL, ILLUMINATION RELAY
TAIL- LIGHT TURN LIGHT
TURN LIGHT
TURN SIGNAL SWITCH
TURN, HAZARD MODULE (BEHIND DASH, RIGHT OF STEERING COLUMN)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> LEFT TURN SIGNAL IND LIGHT
