Saab 9-2X I (2004-2006) knock camshaft position sensor shield sensor shield Wiring diagram
This page shows the only wiring diagram for the component.knock camshaft position sensor shield sensor shield, which is found in the car Saab 9-2X I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram knock camshaft position sensor shield sensor shield (1 of 1)
2.0L TURBO
2.5L
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/WHT WIRE
COMBINATION METER
CRANKSHAFT POSITION SENSOR SHIELD
DATA LINK CONNECTOR
DIAGNOSIS TERMINAL
ELECTRONIC THROTTLE CONTROL
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
FUEL LEVEL SENSOR
GE-1 (2.0L TURBO) (TOP LEFT SIDE OF ENGINE)
GE-1 (2.5L) (TOP RIGHT SIDE OF ENGINE)
GE-2 (2.5L) (TOP LEFT OF ENGINE)
IDLE AIR CONTROL SOLENOID VALVE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL, IGNITOR
KNOCK CAMSHAFT POSITION SENSOR SHIELD SENSOR SHIELD
M/T
NEUTRAL POSITION SWITCH (M/T)
PCV DIAGNOSIS CONNECTOR
RED WIRE
TCM (BEHIND LEFT SIDE OF DASH)
TEST MODE CONNECTOR
VEHICLE SPEED SENSOR (M/T)
VEHICLE SPEED SENSOR (M/T) NEUTRAL POSITION SWITCH (M/T)
Go to component -> Ground distribution circuit (3 of 3) -> KNOCK CAMSHAFT POSITION SENSOR SHIELD SENSOR SHIELD
