Saab 9-2X I (2004-2006) ignition starter, steering lock assembly Wiring diagrams
This page contains all the electrical diagrams for the component. ignition starter, steering lock assembly, in which he is found in the car Saab 9-2X I (2004-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ignition starter, steering lock assembly (1 of 2)
2.0L TURBO
ABS CONTROL MODULE
ABS RELAY
ACCESSORY RELAY
AT SELECT LEVER
AUTO A/C CONTROL MODULE
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY INTEGRATED MODULE
BRAKE FLUID LEVEL WARNING SWITCH
CHECK CONNECTOR
CLOCK
CLUTCH SWITCH (M/T) (2.0L TURBO)
COMBINATION METER
COMBINATION SWITCH
CRUISE CONTROL ACTUATOR (2.0L TURBO)
CRUISE CONTROL MODULE
DAYTIME RUNNING LIGHT CONTROL MODULE
DAYTIME RUNNING LIGHT RELAY AIR MIX ACTUATOR
DAYTIME RUNNING LIGHT RESISTOR
DRIVER SIDE REARVIEW MIRROR HEATER
FRONT ACCESSORY POWER SUPPLY SOCKET
FWD SWITCH
GB-1 (RIGHT REAR OF ENGINE)
GB-2 (NEAR THE LEFT HEADLIGHT)
GB-3
GB-4 (BEHIND RIGHT SIDE OF DASH)
GB-5 (BEHIND CENTER OF DASH)
GLOVE FUEL BOX PUMP ILLUM- RELAY INATION (2.0L LIGHT TURBO)
HEADLIGHT LEVELER SWITCH
IGNITION STARTER, STEERING LOCK ASSEMBLY
IGNITION SWITCH
INHIBITOR SWITCH (A/T) FRONT WIPER MOTOR
JOINT CONNECTOR (AT RIGHT KICK PANEL)
KEYLESS ENTRY CONTROL MODULE
LEFT FRONT DOOR SWITCH
LEFT FRONT FOG LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT (HID MODEL)
LIGHTING
MAIN FAN MOTOR (2.0L TURBO)
MAIN FAN MOTOR (2.5L)
MAIN RELAY
MIRROR HEATER RELAY
MODE ACTUATOR
NCA WIRE
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
REAR DEFOGGER SWITCH
REARVIEW MIRROR SWITCH
RIGHT FRONT DOOR SWITCH
RIGHT FRONT FOG LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT (HID MODEL)
SECURITY CONTROL MODULE
SUB FAN MOTOR (2.0L TURBO)
SUB FAN MOTOR (2.5L)
TO COMPASS MIRROR (DIAGRAM 2 OF 3)
TURN, HAZARD MODULE
WHT/BLU WIRE
WIPER
WIPER DEICER
WIPER DEICER SWITCH
WIPER DEICER TIMER
Go to component -> Ground distribution circuit (1 of 3) -> IGNITION STARTER, STEERING LOCK ASSEMBLY
Wiring diagram ignition starter, steering lock assembly (2 of 2)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/ORG WIRE
BODY INTEGRATED UNIT (BEHIND LEFT SIDE OF DASH)
BRN WIRE
BRN/RED WIRE
COMBINATION METER
FUSE 11
FUSE 13
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-3
GB-7 (UNDER RIGHT FRONT SEAT)
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION STARTER, STEERING LOCK ASSEMBLY
LEFT FRONT DOOR SWITCH (AT REAR OF LEFT FRONT DOOR)
MAIN FUSE BOX (M/B) (ON LEFT SIDE OF ENGINE COMPT) FUSE 6
NCA WIRE
ORG/ WIRE
RED WIRE
RED/WHT WIRE
SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
SEAT BELT WARNING LIGHT IND
WHT WIRE
WHT/RED WIRE
Go to component -> Warning systems circuit -> IGNITION STARTER, STEERING LOCK ASSEMBLY
