Saab 9-2X I (2004-2006) front wiper switch Wiring diagram
This page shows the only wiring diagram for the component.front wiper switch, which is found in the car Saab 9-2X I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front wiper switch (1 of 1)
2.0L TURBO A/T
2.0L TURBO: M/T, 2.5L
ABS CONTROL MODULE
ABS RELAY
AUTO A/C CONTROL MODULE REAR WASHER MOTOR
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CLOCK RADIO
COMBINATION METER
COMBINATION SWITCH
ENGINE COMPT)
ENGINE CONTROL MODULE (2.0L TURBO: A/T)
FROM MAIN FUSE BOX SBF-1 (DIAGRAM 1 OF 4)
FROM MAIN FUSE BOX, HEADLIGHT RELAYS (DIAGRAM 1 OF 4)
FRONT WIPER MOTOR FRONT WASHER MOTOR
FRONT WIPER SWITCH
FUSE 14
FUSE 15
FUSE 9
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) FUSE 13
GENERATOR
GRN WIRE
IGNITION SWITCH
INHIBITOR SWITCH
INTERRUPT RELAY
LOCK
LOCK OFF
MAIN FUSE BOX (M/B) (ON LEFT SIDE OF
NCA WIRE
ON LOCK OFF
ON OFF
REAR WIPER INTERMITTENT MODULE
REAR WIPER MOTOR
RED WIRE
RELAY HOLDER
SBF HOLDER
SBF-2 FUSE
SBF-4 FUSE
SHORT CONNECTOR
STARTER INTERLOCK RELAY
TO AIR CONDITIONING FUSE HOLDER (DIAGRAM 4 OF 4)
TO FUSE, RELAY BOX (DIAGRAM 4 OF 4)
TO FUSE, RELAY BOX FUSE 18 (DIAGRAM 3 OF 4)
TO FUSE, RELAY BOX FUSE 4 (DIAGRAM 4 OF 4)
TO IGNITION RELAY (DIAGRAM 1 OF 4)
W/ SECURITY
W/O SECURITY
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (2 of 4) -> FRONT WIPER SWITCH
