Saab 9-2X I (2004-2006) electronic throttle control Wiring diagrams

A/T BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE CLUTCH SWITCH (M/T) (ON BRACKET, ABOVE CLUTCH PEDAL) COMBINATION METER CRUISE CONTROL SWITCH CRUISE INDICATOR LIGHT DIMMER CIRCUIT ELECTRONIC THROTTLE CONTROL ELECTRONIC THROTTLE CONTROL RELAY (TOP REAR OF ENGINE) ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) FUSE 11 FUSE 13 FUSE 18 FUSE 6 FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) FUSE 16 GE-1 (TOP RIGHT SIDE OF ENGINE) GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/YEL WIRE HORN RELAY HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START JOINT CONNECTOR C (BEHIND RIGHT SIDE OF DASH) LT BLU WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE M/T MAIN MAIN FUSE BOX (M/B) (ON LEFT SIDE OF ENGINE COMPT) MAIN RELAY (BEHIND RIGHT SIDE OF DASH NCA WIRE PNK WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RESUME SBF 5 SET INDICATOR LIGHT SET- STEERING ROLL CONNECTOR TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VEHICLE SPEED SENSOR (ON RIGHT SIDE OF TRANSMISSION CASE) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

2.0L TURBO 2.5L BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/WHT WIRE COMBINATION METER CRANKSHAFT POSITION SENSOR SHIELD DATA LINK CONNECTOR DIAGNOSIS TERMINAL ELECTRONIC THROTTLE CONTROL ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) FUEL LEVEL SENSOR GE-1 (2.0L TURBO) (TOP LEFT SIDE OF ENGINE) GE-1 (2.5L) (TOP RIGHT SIDE OF ENGINE) GE-2 (2.5L) (TOP LEFT OF ENGINE) IDLE AIR CONTROL SOLENOID VALVE IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL, IGNITOR KNOCK CAMSHAFT POSITION SENSOR SHIELD SENSOR SHIELD M/T NEUTRAL POSITION SWITCH (M/T) PCV DIAGNOSIS CONNECTOR RED WIRE TCM (BEHIND LEFT SIDE OF DASH) TEST MODE CONNECTOR VEHICLE SPEED SENSOR (M/T) VEHICLE SPEED SENSOR (M/T) NEUTRAL POSITION SWITCH (M/T)
