Saab 9-2X I (2004-2006) daytime running light resistor Wiring diagram
This page shows the only wiring diagram for the component.daytime running light resistor, which is found in the car Saab 9-2X I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram daytime running light resistor (1 of 1)
2.0L TURBO
ABS CONTROL MODULE
ABS RELAY
ACCESSORY RELAY
AT SELECT LEVER
AUTO A/C CONTROL MODULE
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY INTEGRATED MODULE
BRAKE FLUID LEVEL WARNING SWITCH
CHECK CONNECTOR
CLOCK
CLUTCH SWITCH (M/T) (2.0L TURBO)
COMBINATION METER
COMBINATION SWITCH
CRUISE CONTROL ACTUATOR (2.0L TURBO)
CRUISE CONTROL MODULE
DAYTIME RUNNING LIGHT CONTROL MODULE
DAYTIME RUNNING LIGHT RELAY AIR MIX ACTUATOR
DAYTIME RUNNING LIGHT RESISTOR
DRIVER SIDE REARVIEW MIRROR HEATER
FRONT ACCESSORY POWER SUPPLY SOCKET
FWD SWITCH
GB-1 (RIGHT REAR OF ENGINE)
GB-2 (NEAR THE LEFT HEADLIGHT)
GB-3
GB-4 (BEHIND RIGHT SIDE OF DASH)
GB-5 (BEHIND CENTER OF DASH)
GLOVE FUEL BOX PUMP ILLUM- RELAY INATION (2.0L LIGHT TURBO)
HEADLIGHT LEVELER SWITCH
IGNITION STARTER, STEERING LOCK ASSEMBLY
IGNITION SWITCH
INHIBITOR SWITCH (A/T) FRONT WIPER MOTOR
JOINT CONNECTOR (AT RIGHT KICK PANEL)
KEYLESS ENTRY CONTROL MODULE
LEFT FRONT DOOR SWITCH
LEFT FRONT FOG LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT (HID MODEL)
LIGHTING
MAIN FAN MOTOR (2.0L TURBO)
MAIN FAN MOTOR (2.5L)
MAIN RELAY
MIRROR HEATER RELAY
MODE ACTUATOR
NCA WIRE
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
REAR DEFOGGER SWITCH
REARVIEW MIRROR SWITCH
RIGHT FRONT DOOR SWITCH
RIGHT FRONT FOG LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT (HID MODEL)
SECURITY CONTROL MODULE
SUB FAN MOTOR (2.0L TURBO)
SUB FAN MOTOR (2.5L)
TO COMPASS MIRROR (DIAGRAM 2 OF 3)
TURN, HAZARD MODULE
WHT/BLU WIRE
WIPER
WIPER DEICER
WIPER DEICER SWITCH
WIPER DEICER TIMER
Go to component -> Ground distribution circuit (1 of 3) -> DAYTIME RUNNING LIGHT RESISTOR
