RAM Pickup 3500 (2011-2012) drv seat ft up Wiring diagram
This page shows the only wiring diagram for the component.drv seat ft up, which is found in the car RAM Pickup 3500 (2011-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv seat ft up (1 of 1)
BLK/WHT WIRE
DRIVER SEAT FRONT VERTICAL ADJUSTER MOTOR
DRIVER SEAT HORIZONTAL ADJUSTER MOTOR
DRIVER SEAT REAR VERTICAL ADJUSTER MOTOR
DRIVER SEAT SWITCH
DRV RECLINER DN SW SENS
DRV SEAT FT DN
DRV SEAT FT UP
DRV SEAT HOR FORWARD DRV
DRV SEAT HOR REARWARD DRV
DRV SEAT REAR RISER DN DRV
DRV SEAT REAR RISER UP DRV
DRV SEAT RECLINER UP DRV
FUSED B (+)
GROUND
HOT AT ALL TIMES
LT GRN/DK GRN WIRE
LT GRN/GRY WIRE
LT GRN/LT BLU WIRE
LT GRN/ORG WIRE
LT GRN/TAN WIRE
LT GRN/VIO WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
ORG/ WIRE
ORG/RED WIRE
POWER SEAT CIRCUIT BREAKER
RED WIRE
Go to component -> Driver power seat circuit -> DRV SEAT FT UP
