RAM Pickup 2500 (2011-2012) right tail left lamp backup assembly lamp Wiring diagram
This page shows the only wiring diagram for the component.right tail left lamp backup assembly lamp, which is found in the car RAM Pickup 2500 (2011-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right tail left lamp backup assembly lamp (1 of 1)
34 35 35 18 CAN BUS(+) CAN BUS(-)
7-WAY TRAILER TOW WIRING
B(+) CAN CAN LAMP BUS 2 BUS 2 FEED (+) (-)
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK GRN/DK BLU WIRE
DK GRN/LT BLU WIRE
DK GRN/RED WIRE
DK GRN/YEL WIRE
EXCEPT 6.7L 6.7L
GRY WIRE
HOT AT ALL TIMES
INSIDE REAR VIEW MIRROR
LEFT TAIL LAMP ASSEMBLY
LT BLU WIRE
LT GRN WIRE
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
RED WIRE
RIGHT BACKUP LAMP
RIGHT TAIL LEFT LAMP BACKUP ASSEMBLY LAMP
WHT WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/RED WIRE
Go to component -> Backup lamps circuit -> RIGHT TAIL LEFT LAMP BACKUP ASSEMBLY LAMP
