RAM Pickup 2500 (2011-2012) passenger seat horizontal adjuster motor Wiring diagram
This page shows the only wiring diagram for the component.passenger seat horizontal adjuster motor, which is found in the car RAM Pickup 2500 (2011-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger seat horizontal adjuster motor (1 of 1)
2 1 UP PASS DN PASS
4 6 7 8 PASS HORI RR RD FUSED B (+) GND PASS HORI FR RD
BLK/WHT WIRE
HORI FR
HOT AT ALL TIMES
LT GRN/BRN WIRE
LT GRN/GRY WIRE
LT GRN/ORG WIRE
LT GRN/VIO WIRE
LT GRN/WHT WIRE
ORG LT GRN/ WIRE
ORG/ WIRE
ORG/RED WIRE
PASS REC DN SW
PASS REC UP SW
PASSENGER SEAT HORIZONTAL ADJUSTER MOTOR
PASSENGER SEAT RECLINER ADJUSTER MOTOR
PASSENGER SEAT SWITCH
POWER SEAT CIRCUIT BREAKER
RED WIRE
WHT LT GRN/ WIRE
Go to component -> Passenger power seat circuit -> PASSENGER SEAT HORIZONTAL ADJUSTER MOTOR
