RAM Cab & Chassis 3500 HD (2012-2012) occupant restraint left controller clearance module lamp 2 Wiring diagram
This page shows the only wiring diagram for the component.occupant restraint left controller clearance module lamp 2, which is found in the car RAM Cab & Chassis 3500 HD (2012-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram occupant restraint left controller clearance module lamp 2 (1 of 1)
02 SENSOR MODULE
AUXILIARY BATTERY (6.7L)
BATTERY
BLK WIRE
BLK/TAN WIRE
CENTER CLEARANCE LAMP
DATA LINK CONNECTOR (UNDER CONSOLE)
DOOR LOCK RELAY
EQUIPPED) (IF RIGHT EQUIPPED) VANITY RIGHT LAMP REAR SEAT HEATED SWITCH
FROM TOTALLY INTEGRATED POWER MODULE (DIAGRAM 3 OF 3)
FRONT WASHER PUMP RELAY
HEADLAMP SWITCH
HORN 1
LEFT CLEARANCE LAMP 1
MASS AIR FLOW SENSOR
OCCUPANT RESTRAINT LEFT CONTROLLER CLEARANCE MODULE LAMP 2
ORG/ WIRE
PASSENGER DRIVER DOOR DOOR UNLOCK UNLOCK RELAY RELAY
POWERTRAIN CONTROL MODULE
RADIO
REAR WASHER PUMP RELAY
RIGHT CLEARANCE LAMP 1
RIGHT CLEARANCE LAMP 2
RIGHT FRONT PARK/TURN LAMP
TAN WIRE
TRANSFER CASE STOP SELECTOR LAMP SWITCH SWITCH
TRANSMISSION CONTROL RELAY
W/ MEMORY
W/O MEMORY
Go to component -> Ground distribution circuit (1 of 3) -> OCCUPANT RESTRAINT LEFT CONTROLLER CLEARANCE MODULE LAMP 2
