RAM Cab & Chassis 3500 HD (2012-2012) horns system sound systems Wiring diagram
This page shows the only wiring diagram for the component.horns system sound systems, which is found in the car RAM Cab & Chassis 3500 HD (2012-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram horns system sound systems (1 of 1)
1 2 WHEEL FEED WHEEL RTN
3 2 1 FUSED B(+) LIN BUS GND
3 2 FUSED B (+) LIN BUS
7 6 8 GND FUSED B (+) LIN BUS
BLK WIRE
BLK/LT GRN WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/VIO WIRE
FUSE
GRY/ORG WIRE
GRY/WHT WIRE
HORNS SYSTEM SOUND SYSTEMS
HOT AT ALL TIMES
LEFT STEERING WHEEL SWITCH
LOWER BANK SWITCH
LP DIM SIG
MUX RTN
MUX SIG
ORG/BRN WIRE
RED WIRE
RED/GRY WIRE
RIGHT STEERING WHEEL SWITCH
STEERING CONTROL MODULE (LEFT SIDE OF DASH)
STEERING WHEEL HEATER
STEERING WHEEL HEATER SENSOR (IN STEERING WHEEL)
TOTALLY INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT)
VIO WIRE
VIO/LT BLU WIRE
VIO/ORG WIRE
WHT WIRE
WHT/DK GRN WIRE
YEL WIRE
Go to component -> Heated steering wheel circuit -> HORNS SYSTEM SOUND SYSTEMS
