RAM Cab & Chassis 3500 HD (2012-2012) exhst gas temp lr/cc sol ctrl ctrl fuel pmp sig ovrde rly coil rtn asd rly fd Wiring diagram

A/C CLTCH COIL ACCEL PED POSTN ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY) BLK WIRE BLK/GRY WIRE BRN WIRE BRN/BLK WIRE BRN/DK GRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CAN 2 J 1939(+) CAN J 1939(+) CAN BUS(-) ACC PED POS SENS RTN CAN BUS (+) PED POS SNSR RTN 2 PED POS 1 SNSR SIG COMPUTER DATA LINES SYSTEM DELTA PRESS DK BLU/BRN WIRE DK BLU/ORG WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/DK BLU WIRE DK GRN/LT BLU WIRE DK GRN/ORG WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE DSL HIGH SIDE DRVR RTN 4 EXHAUST PRESSURE SENSOR 1/2 EXHST GAS TEMP LR/CC SOL CTRL CTRL FUEL PMP SIG OVRDE RLY COIL RTN ASD RLY FD FUEL LVL FUEL PMP FUEL PUMP MODULE FUEL SNDR LINE PRESSURE SENSOR (TOP LEFT REAR OF ENGINE) LNE PRESS LT BLU/ORG WIRE LT GRN/TAN WIRE LVL SIG MTR FD PNK/YEL WIRE POS 1 SNSR SIG POS 2 SNSR SIG POSTN SNSR RTN POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) PRESS SOL SW SIG RED/ORG WIRE SEC FD SNSR PRIM FD SNSR RTN SNSR RTN 2 SNSR SEC FD SOOT SPD CTRL SW FD STARTING/CHARGING SYSTEM STEERING CONTROL MODULE (LEFT SIDE OF DASH) SW SPD CTRL RDNT SW SPD CTRL RDNT CAT INTK TEMP UD SOL CTRL ASD RTN SW SPD CTRL RTN TRANS SIG TRNS RNG SIG 3 VIO WIRE VIO/BRN WIRE VIO/ORG WIRE WHT/BRN WIRE WHT/DK BLU WIRE WHT/DK GRN WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/LT BLU WIRE YEL/ORG WIRE YEL/PNK WIRE YEL/TAN WIRE
