RAM Cab & Chassis 3500 HD (2012-2012) brake transmission shift interlock Wiring diagram
This page shows the only wiring diagram for the component.brake transmission shift interlock, which is found in the car RAM Cab & Chassis 3500 HD (2012-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake transmission shift interlock (1 of 1)
18 35 35 34 CAN C BUS (-) CAN C BUS (+)
5.7L
6.7L 5.7L
ASTK UP
BATT FD (5.7L) RUN/START (6.7L)
BLK/LT GRN WIRE
BLK/TAN WIRE
BRAKE TRANSMISSION SHIFT INTERLOCK
BRK SIG
BRK SIG 2
BRN/YEL WIRE
BTSI SOL ULK
CLUSTER
CLUTCH INTERLOCK SWITCH (5.7L) (LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DIM 3 IP
DK GRN/DK BLU WIRE
DK GRN/LT BLU WIRE
DK GRN/RED WIRE
DK GRN/YEL WIRE
ERS AUTOSTICK SWITCH
FUSE
GROUND
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT W/ RUN/ START RELAY ENERGIZED
IGN FD
IGN RS
IGN RUN/ RUN/START
LT BLU/DK GRN WIRE
ORG/GRY WIRE
PNK WIRE
PNK/TAN WIRE
PNK/WHT WIRE
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
PRK/NEUT SIG
RED WIRE
SOLENOID (BASE OF SHIFTER)
STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT)
SW RTN
TOTALLY INTEGRATED POWER MODULE CIRCUIT (LEFT FRONT OF BOARD ENGINE COMPT)
TRANSMISSION
TRANSMISSION SOLENOID/TRS ASSEMBLY (LEFT SIDE OF
TRS RNG PARK
WHT/GRY WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/ORG WIRE
WHT/YEL WIRE
WIN WIRELESS IGNITION NODE
YEL/DK BLU WIRE
Go to component -> Shift interlock circuit -> BRAKE TRANSMISSION SHIFT INTERLOCK
