RAM 1500 V (2018-2024) paddle shift sw sig Wiring diagram
This page shows the only wiring diagram for the component.paddle shift sw sig, which is found in the car RAM 1500 V (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram paddle shift sw sig (1 of 1)
3.0L TURBO DIESEL
3.6L, 5.7L, 5.7L HYBRID
6.2L
BLK WIRE
BODY CONTROL MODULE
BRN/ORG WIRE
CAN C (+)
COMPUTER DATA LINES SYSTEM
CTRL O/P
ELECTRONIC SHIFT MODULE
EXCEPT 3.0L TURBO DIESEL
EXCEPT 6.2L
FUSE 24
FUSE 42
FUSE 53
FUSED B (+)
GND STEERING WHEEL SW ILLUMINATION
GRY WIRE
HORN SWITCH
HOT AT ALL TIMES
IGN OFF/RUN/START
IGN OFF/RUN/START CTRL O/P
INTERIOR POWER DISTRIBUTION CENTER ASSEMBLY
LEFT STEERING WHEEL SWITCH
ORG/DK GRN WIRE
PADDLE SHIFT SW SIG
PADDLE SHIFT SWITCH
PNK/WHT WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
PRIVATE CAN (-)
RED WIRE
RED/YEL WIRE
SPEED CONTROL SWITCH
STEERING COLUMN CONTROL MODULE
STEERING WHEEL SW ILLUMINATION
TRANSMISSION CONTROL MODULE
VIO/WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> A/t circuit -> PADDLE SHIFT SW SIG
