RAM 1500 IV (2011-2024) sunroof vent sw sens Wiring diagram

This page shows the only wiring diagram for the component.sunroof vent sw sens, which is found in the car RAM 1500 IV (2011-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram sunroof vent sw sens (1 of 1)

Wiring diagram sunroof vent sw sens for RAM 1500 IV (2011-2024)

Get access

BLK WIRE BLU WIRE FUSE 35 FUSE 66 FUSED B (+) FUSED IGN SW O/P GROUND HOT AT ALL TIMES HOT W/ RUN/ ACCESSORY RELAY 1 ENERGIZED ORG/BLU WIRE ORG/GRN WIRE ORG/TAN WIRE ORG/YEL WIRE PNK WIRE POWER DISTRIBUTION CENTER ASSEMBLY RED WIRE SUNROOF CLS SW SENS SUNROOF DIAGNOSTIC SUNROOF DIAGNOSTIC 2 SUNROOF DIAGNOSTIC 3 SUNROOF MODULE (CENTER REAR OF ROOF) SUNROOF OPEN SW SENS SUNROOF SW SPLY SUNROOF SWITCH SUNROOF VENT SW SENS WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE

Go to component: -> Power top/sunroof circuit -> SUNROOF VENT SW SENS
