RAM 1500 IV (2011-2024) standard cab except standard cab base premium wiring diagram
This page shows the only wiring diagram for the component.standard cab except standard cab base premium, which is found in the car RAM 1500 IV (2011-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
standard cab except standard cab base premium wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DRIVER DOOR HANDLE LAMP
DRIVER DOOR MODULE
DRIVER SIDE MAP POCKET LAMP
DRV DR AMB LAMP FD
DRV DR AMB LAMP FD DRV DR LIGHTING RTN
DRV DR LIGHTING RTN
FOOTWELL LAMP FD
FOOTWELL LMP FD
FRONT CUPHOLDER LAMP
FSD B(+)
LEFT REAR DOOR HANDLE LAMP
LEFT REAR MAP POCKET LAMP
PASS DR AMB LAMP FD
PASS DR AMB LAMP FD PASS DR LIGHTING RTN
PASS DR LIGHTING RTN
PASSENGER DOOR HANDLE LAMP
PASSENGER DOOR MODULE
PASSENGER SIDE MAP POCKET LAMP
RED WIRE
RIGHT REAR DOOR HANDLE LAMP
RIGHT REAR MAP POCKET LAMP
STANDARD CAB EXCEPT STANDARD CAB BASE PREMIUM
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL/BRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> STANDARD CAB EXCEPT STANDARD CAB BASE PREMIUM
