RAM 1500 IV (2011-2024) exhaust gas temperature catalyst sensor wiring diagram
This page shows the only wiring diagram for the component.exhaust gas temperature catalyst sensor, which is found in the car RAM 1500 IV (2011-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
exhaust gas temperature catalyst sensor wiring diagram (1 of 1)
5 V SPLY
BRN/BLU WIRE
BRN/DK BLU WIRE
BRN/DK GRN WIRE
BRN/GRY WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DK BLU WIRE
DK BLU/DK GRN WIRE
DK BLU/GRN WIRE
DK BLU/GRY WIRE
DK BLU/ORG WIRE
DK BLU/RED WIRE
DK BLU/TAN WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/RED WIRE
EGR AIR FLOW CONTROL VALVE
EGR COOLING BYPASS ACTUATOR
EGR CTRL 1
EGR CTRL 2
EGR SENS GND
EGR SIG
EGR TEMPERATURE SENSOR
EGR VALVE ASSEMBLY
END POSITION
EXHAUST GAS TEMPERATURE CATALYST SENSOR
EXHAUST GAS TEMPERATURE SENSOR 1/2
FSD ASD RLY O/P
POSITION RTN
RETURN
RLY O/P
SENS GND
SENS SIG
SENS SIGNAL
SERVO MTR CTRL
SIGNAL
SUPPLY
SWIRL ACTUATOR
SWIRL VALVE POSITION SENSOR 1
SWIRL VALVE POSITION SENSOR 2
TEMP SIGNAL
TP 1 SIG
TP SENS RTN
TTVA MTR (+)
VALVE (+) SIG
Go to component -> Wiring diagram engine performance 3.0l turbo diesel (6 of 8) -> EXHAUST GAS TEMPERATURE CATALYST SENSOR
