RAM 1500 IV (2011-2024) chmsl lamp Wiring diagrams
This page contains all the electrical diagrams for the component. chmsl lamp, in which he is found in the car RAM 1500 IV (2011-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
chmsl lamp wiring diagram (1 of 3)
1500 2500 HD, 3500 HD
AFTERMARKET CENTER HIGH MOUNTED STOP LAMP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BRK
BRK LAMP O/P
CAN IHS (-)
CARGO LAMP DRV
CHMSL LAMP
COMPUTER DATA
COMPUTER DATA LINES SYSTEM
DK GRN/ORG WIRE
FUSE 6
FUSE/RELAY BLOCK
GRN/WHT WIRE
GROUND DISTRIBUTION SYSTEM
HAZ SW SNS
HOT AT ALL TIMES
INTEGRATED CENTER STACK SWITCH BANK MODULE
LAMP
LEFT LICENSE LAMP
LEFT TAIL LAMP ASSEMBLY
LH BKUP LAMP DRV
LH STOP LAMP DRV
LICENSE
LIN BUS 1
LIN BUS CBC 3
LINES SYSTEM
LR PARK LAMP DRV
ORG/ WIRE
ORG/DK BLU WIRE
PLATE
PNK/YEL WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RIGHT LICENSE LAMP
RUN RLY CTRL
SWITCHED B+
UPPER BANK SWITCH
VIO/BRN WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/DK GRN WIRE
WHT/GRN WIRE
WHT/TAN WIRE
WHT/VIO WIRE
Go to component -> Exterior lamps circuit, base (2 of 3) -> CHMSL LAMP
chmsl lamp wiring diagram (2 of 3)
1500 2500 HD, 3500 HD
AFTERMARKET CENTER HIGH MOUNTED STOP LAMP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BRK
BRK LAMP O/P
CAN IHS (-)
CARGO LAMP DRV
CHMSL LAMP
COMPUTER DATA
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN/BRN WIRE
DK GRN/ORG WIRE
FSD B(+)
FUSE 6
FUSE/RELAY BLOCK
GRN/WHT WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BLU WIRE
GRY/YEL WIRE
HAZ SW SNS
HOT AT ALL TIMES
INTEGRATED CENTER STACK SWITCH BANK MODULE
LAMP
LEFT LICENSE LAMP
LEFT SPOT LAMP
LEFT TAIL LAMP ASSEMBLY
LH BKUP LAMP DRV
LH STOP LAMP DRV
LICENSE
LIN BUS 1
LIN BUS CBC 3
LINES SYSTEM
LR LIGHT FLT SNS
LR PARK LAMP DRV
NAVIGATION SYSTEM
ORG/ WIRE
ORG/DK BLU WIRE
PLATE
PNK/YEL WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RIGHT LICENSE LAMP
RIGHT SPOT LAMP
RUN RLY CTRL
SWITCHED B+
UPPER BANK SWITCH
VIDEO COM 2
VIDEO SHLD 2
VIDEO SIG 2 -
VIO/BRN WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/DK GRN WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/TAN WIRE
WHT/VIO WIRE
Go to component -> Exterior lamps circuit, premium (2 of 3) -> CHMSL LAMP
chmsl lamp wiring diagram (3 of 3)
AIR SUSPENSION CONTROL MODULE
ARMREST POWER OUTLET
BASE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
CENTER CONSOLE
CHMSL LAMP
CIGAR LIGHTER
DRIVER LUMBAR SEAT ADJUSTER SWITCH
DRIVER SEAT SWITCH
ELECTRIC HEATED BACKLITE
FROM POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 4 OF 4)
HEATED SEATS MODULE
INVERTER MODULE
LEFT HEADLAMP LAMP
LEFT REAR DOOR HANDLE LAMP
LEFT REAR DOOR LATCH
LEFT REAR FOOTWELL LAMP
LEFT REAR HEATED SEAT SWITCH
LEFT REAR MAP POCKET LAMP
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SEAT CUSHION HEATER
LEFT SEAT BACK HEATER
LEFT SEAT CUSHION HEATER
LEFT TAIL LAMP ASSEMBLY
MEMORY SEAT MODULE
PARK ASSIST MODULE
PASSENGER DOOR LATCH
PASSENGER DOOR MODULE
PASSENGER LUMBAR SEAT ADJUSTER SWITCH
PASSENGER SEAT SWITCH
POWER DISTRIBUTION CENTER ASSEMBLY FUEL HEATER 2 RELAY
POWER OUTLET
PREMIUM
RADIO FREQUENCY HUB MODULE
REAR CONSOLE POWER OUTLET
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP LAMP
RIGHT REAR DOOR HANDLE LAMP
RIGHT REAR DOOR LATCH
RIGHT REAR FOOTWELL LAMP
RIGHT REAR HEATED SEAT SWITCH
RIGHT REAR MAP POCKET LAMP
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT CUSHION HEATER
RIGHT SEAT BACK HEATER
RIGHT SEAT CUSHION HEATER
W/ HEATED SEATS W/O HEATED SEATS
Go to component -> Ground distribution circuit (3 of 4) -> CHMSL LAMP
