RAM 1500 IV (2011-2024) armrest power outlet Wiring diagrams
This page contains all the electrical diagrams for the component. armrest power outlet, in which he is found in the car RAM 1500 IV (2011-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram armrest power outlet (1 of 2)
AIR SUSPENSION CONTROL MODULE
ARMREST POWER OUTLET
BASE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
CENTER CONSOLE
CHMSL LAMP
CIGAR LIGHTER
DRIVER LUMBAR SEAT ADJUSTER SWITCH
DRIVER SEAT SWITCH
ELECTRIC HEATED BACKLITE
FROM POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 4 OF 4)
HEATED SEATS MODULE
INVERTER MODULE
LEFT HEADLAMP LAMP
LEFT REAR DOOR HANDLE LAMP
LEFT REAR DOOR LATCH
LEFT REAR FOOTWELL LAMP
LEFT REAR HEATED SEAT SWITCH
LEFT REAR MAP POCKET LAMP
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SEAT CUSHION HEATER
LEFT SEAT BACK HEATER
LEFT SEAT CUSHION HEATER
LEFT TAIL LAMP ASSEMBLY
MEMORY SEAT MODULE
PARK ASSIST MODULE
PASSENGER DOOR LATCH
PASSENGER DOOR MODULE
PASSENGER LUMBAR SEAT ADJUSTER SWITCH
PASSENGER SEAT SWITCH
POWER DISTRIBUTION CENTER ASSEMBLY FUEL HEATER 2 RELAY
POWER OUTLET
PREMIUM
RADIO FREQUENCY HUB MODULE
REAR CONSOLE POWER OUTLET
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP LAMP
RIGHT REAR DOOR HANDLE LAMP
RIGHT REAR DOOR LATCH
RIGHT REAR FOOTWELL LAMP
RIGHT REAR HEATED SEAT SWITCH
RIGHT REAR MAP POCKET LAMP
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT CUSHION HEATER
RIGHT SEAT BACK HEATER
RIGHT SEAT CUSHION HEATER
W/ HEATED SEATS W/O HEATED SEATS
Go to component -> Ground distribution circuit (3 of 4) -> ARMREST POWER OUTLET
Wiring diagram armrest power outlet (2 of 2)
3.0L TURBO DIESEL
A/C HEATER MODULE
ARMREST POWER OUTLET
B(+)
BLK WIRE
BLOWER MOTOR RELAY
BODY CONTROL MODULE
BRN/ORG WIRE
BRN/RED WIRE
CENTER CONSOLE EXCEPT CENTER CONSOLE
FROM FUSE 21 (DIAGRAM 1 OF 7)
FUSE 104
FUSE 19
FUSE 57
FUSE 82
FUSE 84
FUSE 85
FUSE 94
FUSE 95
FUSE 96
FUSE 97
FUSE 98
FUSED
GRN WIRE
HEATED SEATS MODULE
INSTRUMENT PANEL POWER OUTLET
INTEGRATED CENTER STACK SWITCH BANK MODULE
LEFT REAR HEATED SEAT SWITCH
OCCUPANT RESTRAINT CONTROLLER MODULE
PARK ASSIST MODULE
PNK WIRE
PNK/YEL WIRE
POWERTRAIN MODULE RELAY
REAR VIDEO CAMERA
RED WIRE
RIGHT REAR HEATED SEAT SWITCH
RIGHT TRAILER TOW RELAY
RUN 1 RELAY
RUN 2 RELAY
SBW SHIFT BY WIRE MODULE
SCR 1 RELAY
SCR 2 RELAY
STEERING CONTROL MODULE
TO FUSE 55 (DIAGRAM 3 OF 7)
TO RUN/ ACCESSORY 1 RELAY (DIAGRAM 3 OF 7)
TRANSFER CASE SWITCH
TRANSMISSION CONTROL MODULE
UPPER BANK SWITCH
W/O START/STOP SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (2 of 7) -> ARMREST POWER OUTLET
