Rear heated seats circuit for Porsche Panamera Turbo 971 (2016-2020)
Rear heated seats circuit
AIR CONDITIONING SYSTEM CONTROL UNIT
BACKREST HEATING ELEMENT
BACKREST TEMPERATURE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BRN WIRE
CODIERPIN 1
FUSE 4
FUSE 7
FUSE CARRIER 4
FUSE CARRIER 6
GRN/BLU WIRE
HOT AT ALL TIMES
LEFT REAR SEAT HEATED BACKREST
LEFT REAR SEAT HEATED BENCH SEAT CUSHION
LEFT REAR SEAT HEATING CONTROL UNIT
LEFT REAR SEAT LATERAL SUPPORT HEATER
LEFT SEAT FUSE BOX
LIN
LIN 5
NTC-
RED/BLK WIRE
RIGHT REAR SEAT HEATED BACKREST
RIGHT REAR SEAT HEATED BENCH CUSHION
RIGHT REAR SEAT HEATING CONTROL UNIT
RIGHT REAR SEAT LATERAL SUPPORT HEATER
RIGHT SEAT FUSE BOX
SEAT HEATING ELEMENT
SEAT TEMPERATURE
SPLY
TERM 30
TERM 31
VIO/YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
