Electronic power steering circuit for Porsche Panamera Turbo S 971 facelift (2020-2023)
Electronic power steering circuit
BATTERY ISOLATION UNIT
BLK WIRE
BLK/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FLEXRAY 1-
FUSE 1
FUSE 2
FUSE CARRIER 9
GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED
LEFT SEAT FUSE BOX
PNK FLEXRAY 1+ WIRE
RED WIRE
SERVOTRONIC CONTROL UNIT (ON STEERING RACK)
TERM 15
TERM 30
TERM 31
