Porsche Panamera GTS 970 facelift (2013-2016) rear window heated relay Wiring diagram
This page shows the only wiring diagram for the component.rear window heated relay, which is found in the car Porsche Panamera GTS 970 facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window heated relay (1 of 1)
ACC CONTROL UNIT RELAY
AIR CONDITIONING RELAY
BLOCKING CAPACITOR GROUND
BLU WIRE
BRN WIRE
CAPACITOR GROUND
CONDENSER BLOCK CIRCUIT
DC/DC CONVERTER 1
DC/DC CONVERTER 2
EXCEPT HYBRID
EXHAUST FLAP VALVE
GATEWAY CONTROL UNIT
HIGH MOUNTED STOP LIGHT
HIGH-VOLT BATTERY SYSTEM
HV CHARGER
LEFT NUMBER PLATE LIGHT
LEFT REAR HEIGHT SENSOR
LEFT REAR LID LIGHT
LEFT TAILLIGHT ASSEMBLY
MAIN FUSE BOX
MASTER LANE CHANGE ASSISTANT
PASM CONTROL UNIT
PDCC CONTROL UNIT
POWER LIFTGATE BUTTON
POWER LIFTGATE CONTROL UNIT
PTC HEATER BATTERY
RDK CONTROL UNIT
REAR BCM
REAR DIFFERENTIAL LOCK CONTROL UNIT
REAR WINDOW HEATED RELAY
REAR WINDOW HEATER RELAY
RIGHT NUMBER PLATE LIGHT
RIGHT REAR BRAKE PAD WEAR INDICATOR
RIGHT TAILLIGHT ASSEMBLY
SLAVE LANE CHANGE ASSISTANT
SPOILER FLAP RELAY
SUPERCHARGER LEVEL CONTROL
SUPPRESSION CAPACITOR
TAILGATE LOCK MOTOR
TERM 85
TRAILER HITCH CONTROL UNIT
TRAILER SOCKET
Go to component -> Ground distribution circuit (6 of 7) -> REAR WINDOW HEATED RELAY
