Porsche Panamera GTS 970 facelift (2013-2016) rear orientation light Wiring diagrams

AMBIENT LIGHTING BLK/RED WIRE BLU/YEL WIRE BRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM DOOR EXIT OP CTRL UNIT FRONT PACKAGE TRAY LIGHT FUSE 42 GROUND GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT CENTER READING LIGHT LEFT CENTER REAR READING LIGHT LEFT MAKE-UP MIRROR LEFT REAR INTERIOR LIGHT LEFT REAR VANITY MIRROR LIN LR INT LIGHT, READING LIGHT LR INT/READING LIGHT SW SIG ODDMENTS TRAY LIGHTING OPERATING UNIT DOOR CTRL OPERATING UNIT TERM 31 ORIENTATION LIGHT POSITIVE READING LIGHT SWITCH READING LT, INTERIOR LT REAR CENTER AMBIENT LIGHTING REAR ORIENTATION LIGHT REAR SYMBOL LIGHTING RED/YEL WIRE RIGHT CENTER INTERIOR LIGHT RIGHT CENTER READING LIGHT RIGHT CENTER REAR READING LIGHT RIGHT FRONT FUSE BOX RIGHT MAKE-UP MIRROR RIGHT REAR DOOR CONTROL UNIT RIGHT REAR DOOR GUARD LIGHT RIGHT REAR DOOR ODDMENTS TRAY LIGHTING RIGHT REAR DOOR POWER WINDOW BUTTON RIGHT REAR INNER DOOR HANDLE LIGHTING RIGHT REAR INTERIOR LIGHT RIGHT REAR VANITY MIRROR ROOF CONSOLE RR INT LIGHT, READING LIGHT RR INT/READING LIGHT SW SIG TERM 30 TERM 31 VIO/WHT WIRE VIO/YEL WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/WHT WIRE

AMBIENT LIGHTING, REAR CENTER BLU WIRE BRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM FUSE 42 GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HANDSFREE MICROPHONE + HOT AT ALL TIMES LEFT FRONT FUSE BOX LIN LR CNTR READING LIGHT LR INTERIOR LIGHT, READING LIGHT LR READING LIGHT MICROPHONE SHIELD MICROPHONE SIGNAL REAR LIGHT GROUND REAR ORIENTATION LIGHT REAR SYMBOL LIGHTING RED WIRE RED/YEL WIRE ROOF CONSOLE RR CNTR READING LIGHT RR INTERIOR LIGHT, READING LIGHT RR READING LIGHT SOUND SYSTEMS TERM 30 TERM 30 G TERM 31 VIO/YEL WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE
