Porsche Panamera GTS 970 facelift (2013-2016) mirr sel ctrl sw Wiring diagram
This page shows the only wiring diagram for the component.mirr sel ctrl sw, which is found in the car Porsche Panamera GTS 970 facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirr sel ctrl sw (1 of 1)
BRN WIRE
BRN/VIO WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR BUTTON MODULE
DRIVER'S DOOR CONTROL UNIT (CENTER OF DRIVER DOOR)
EC GLASS MIRROR
EC GLASS MIRROR GND
EC MIRROR
EC MIRROR GND
FOLDING MIRROR POS 1
FOLDING MIRROR POS 2
FRONT PASSENGER'S DOOR CONTROL UNIT
FUSE 21
FUSE 41
GRY WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HEATING
HOT AT ALL TIMES
LEFT DOOR MIRROR HEATER
LEFT EC HEATED MIRROR
LEFT FRONT FUSE BOX
LEFT MIRROR FOLDING MOTOR
LEFT SERVO MOTOR EXTERIOR MIRROR
MIRR ADJ CTRL SW
MIRR ADJUSTMENT
MIRR CHANGEOVER SWITCH
MIRR SEL CTRL SW
MIRROR ADJUST MOTOR X
MIRROR ADJUST MOTOR X MIRROR ADJUST MOTOR Y
MIRROR ADJUST MOTOR Y
MIRROR MOTOR SPLY
MOTOR Y
ORG/BRN WIRE
ORG/GRN WIRE
RED/BLK WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT DOOR MIRROR HEATER
RIGHT EC HEATED MIRROR
RIGHT FRONT FUSE BOX
RIGHT MIRROR FOLDING MOTOR
RIGHT SERVO MOTOR EXTERIOR MIRROR
SYSTEM
TERM 30
TERM 31
TERM 31 POWER MIRROR
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
W/ AUTOMATIC DIMMING W/O AUTOMATIC DIMMING
WHT WIRE
Go to component -> Power mirrors circuit -> MIRR SEL CTRL SW
