Porsche Panamera GTS 970 facelift (2013-2016) function display on function ind off Wiring diagrams

ADJUSTMENT ANGLE ADJUSTMENT ANGLE ADJUSTMENT 1 ANGLE ADJUSTMENT 2 BACKREST ADJUSTMENT 1 BACKREST ADJUSTMENT 2 BACKREST ADJUSTMENT SW BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BUTTON 1, 2 OFF CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM DRIVER DOOR MEMORY BUTTON MODULE DRIVER SEAT ADJUSTMENT OUTPUT CONTROL UNIT DRIVER SEAT BACKREST ADJUSTMENT MOTOR DRIVER SEAT RECLINE ADJUSTMENT MOTOR DRIVER'S DOOR CONTROL UNIT DRIVER'S SEAT CONTROL UNIT DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR FUNCTION DISPLAY ON FUNCTION IND OFF FUSE 21 FUSE 51 GND SW GRN/VIO WIRE GRY/BLK WIRE GRY/GRN WIRE HALL SNSR HALL SNSR GND HEIGHT ADJUSTMENT 1 HEIGHT ADJUSTMENT 2 HOT AT ALL TIMES HOT W/ KL LEFT FRONT FUSE BOX LOAD MEMORY MEMORY OFF BUTTON MEMORY OFF LED FUNCTION IND ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE SEAT FORE/ AFT ADJUSTMENT MOTOR SEAT HEIGHT ADJUSTMENT SET BUTTON TERM 30 TERM 31 WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE

ADJUSTMENT BTN GND ADJUSTMENT BTN SIG ADJUSTMENT CODED BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE BUTTON 1, 2 OFF CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM DRIVER DOOR MEMORY BUTTON MODULE DRIVER'S DOOR CONTROL UNIT FUNCTION DISPLAY ON FUNCTION IND OFF FUSE 21 FUSE 9 GRN/BLK WIRE GRN/VIO WIRE GRN/YEL WIRE HALL SENS HALL SENS FORE/AFT + HALL SENS HEIGHT + HOT AT ALL TIMES LEFT FRONT FUSE BOX LIN MEMORY MEMORY OFF BUTTON MEMORY OFF LED FUNCTION IND MOTOR MOTOR +FORE/AFT ORG/BRN WIRE ORG/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SET BUTTON STEERING COLUMN ADJUSTMENT CONTROL UNIT STEERING COLUMN ADJUSTMENT SWITCH STEERING COLUMN FORE/AFT ADJUSTMENT MOTOR STEERING COLUMN HEIGHT ADJUSTMENT MOTOR TERM 30 TERM 31 VIO/BLU WIRE YEL WIRE
