Porsche Panamera 4S 971 (2016-2020) right front seat extension heater element Wiring diagram
This page shows the only wiring diagram for the component.right front seat extension heater element, which is found in the car Porsche Panamera 4S 971 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front seat extension heater element (1 of 1)
AIR BAG 1-
AIR BAG 2+
AIR BAG GROUND
AIR BAG STEERING COLUMN 1
BLK WIRE
BLK/BRN WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COIL CONNECTOR
COMPUTER DATA LINES SYSTEM
EARTH POINT 2 SEAT CONTROL UNIT
ELEMENT
FRONT PASSENGER SIDE A-PILLAR AIR BAG CRASH SENSOR
FRONT PASSENGER SIDE AIR BAG PRESSURE SENSOR
FRONT PASSENGER SIDE C-PILLAR REAR AIR BAG CRASH SENSOR
FRONT PASSENGER SIDE PEDESTRIAN PROTECTION CRASH SENSOR
FRONT PASSENGER SIDE SEAT POSITION SENSOR
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GROUND
GRY WIRE
HEATER
HEATING
NEGATIVE
NTC-
POSITIVE
POWER, CONTROL ELECTRONICS CRASH SENSOR
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT BELT SWITCH
RIGHT FRONT SEAT EXTENSION HEATER ELEMENT
RIGHT FRONT SEAT HEATED CUSHION
SEAT OCCUPIED RECOGNITION CONTROL UNIT
SHIELD
SIGNAL
STEERING WHEEL GROUND
STEERING WHEEL)
TERM 15
TERM 30
TERM 31
VIO WIRE
VIO/GRN WIRE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> RIGHT FRONT SEAT EXTENSION HEATER ELEMENT
