Porsche Panamera 4S 971 (2016-2020) pwm output module 3 Wiring diagrams
This page contains all the electrical diagrams for the component. pwm output module 3, in which he is found in the car Porsche Panamera 4S 971 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pwm output module 3 (1 of 2)
5 V SUPPLY SENSOR
AIR HUMIDITY RAIN, LIGHT SENSOR
ANODE CHANNEL 1
BLK WIRE
BRN WIRE
CAN HIGH
CAN LOW
CATHODE CHANNEL 1
CHANNEL
CODING 1
CODING PIN
CODING PIN CHANNEL 1
FUSE 2
FUSE CARRIER 3
GND SENSORS
HEADLIGHT VERTICAL CTRL MTR 1 -
HEADLIGHT VERTICAL CTRL MTR 2 -
HEADLIGHTS MOTOR 1 -
HEADLIGHTS MOTOR 2 +
HOT AT ALL TIMES
LED A
LED ANODE
LED CATHODE
LED K
LEFT DYNAMIC CORNERING LIGHT CONTROL MOTOR
LEFT END-OUTLINE MARKER LAMP BULB 1
LEFT END-OUTLINE MARKER LAMP BULB 3
LEFT HEADLIGHT RANGE CONTROL MOTOR
LEFT HEADLIGHT TEMPERATURE SENDER 1
LEFT LED HEADLIGHT OUTPUT MODULE 2
LEFT LED HEADLIGHT OUTPUT MODULE 4
LEFT SEAT FUSE BOX
MOTOR 1
MOTOR 2
MTR 1 -
MTR 2 -
NTC CHANNEL 1
POSITION SENSOR
PWM OUTPUT MODULE 3
R/L DETECTION
RED WIRE
SIGNAL
TEMP SENS
TERM 15
TERM 30
TERM 31
THERM PROT
VIO/WHT WIRE
Go to component -> Headlights circuit, w/ led headlights (2 of 6) -> PWM OUTPUT MODULE 3
Wiring diagram pwm output module 3 (2 of 2)
5 V SUPPLY SENSOR
ANODE CHANNEL 1
BLK WIRE
CAN HIGH
CAN LOW
CATHODE CHANNEL 1
CHANNEL
CODING 1
CODING PIN
CODING PIN CHANNEL 1
GND SENSORS
HEADLIGHT VERTICAL CTRL MTR 1 -
HEADLIGHT VERTICAL CTRL MTR 2 -
HEADLIGHTS MOTOR 1 -
HEADLIGHTS MOTOR 2 +
LED A
LED ANODE
LED CATHODE
LED K
LEFT HEADLIGHT CONTROL MOTOR
MOTOR 1
MOTOR 2
MTR 1 -
MTR 2 -
MTR GND
NTC CHANNEL 1
POSITION SENSOR
PWM OUTPUT MODULE 3
R/L DETECTION
RIGHT DYNAMIC CORNERING LIGHT CONTROL MOTOR
RIGHT HEADLIGHT RANGE CONTROL MOTOR
RIGHT HEADLIGHT TEMPERATURE SENDER 1
RIGHT LED HEADLIGHT OUTPUT MODULE 2
RIGHT LED HEADLIGHT OUTPUT MODULE 4
SIGNAL
TEMP SENS
TERM 15
TERM 30
TERM 31
THERM PROT
Go to component -> Headlights circuit, w/ led headlights (4 of 6) -> PWM OUTPUT MODULE 3
