Porsche Panamera 4S 971 (2016-2020) midi fuse 4 Wiring diagram
This page shows the only wiring diagram for the component.midi fuse 4, which is found in the car Porsche Panamera 4S 971 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram midi fuse 4 (1 of 1)
AIR BAG CONTROL UNIT
BAG HV-
BATTERY FAN 1
BRN WIRE
CAN HYBRID HIGH
CAN HYBRID LOW
COMPUTER DATA LINES SYSTEM
FAN
FROM FUSE 4 (DIAGRAM 5 OF 11)
FROM MAIN FUSE BOX (DIAGRAM 1 OF 11)
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE HOLDER H
GRN WIRE
GRN/BRN WIRE
GRN/RED WIRE
MIDI FUSE 3
MIDI FUSE 4
N/A
NOT USED
ORG/BRN WIRE
ORG/WHT WIRE
PWM
REAR ANTI-ROLL BAR CONTROL UNIT 2
RED WIRE
TERM 30
TERM 30 CTRL UNIT
TERM 30 LOAD
TERM 31
TERM 31/42
TERM 40
TERM 41
TERMINAL 40 WIRING JUNCTION
VIO WIRE
VIO/BRN WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (11 of 11) -> MIDI FUSE 4
