Porsche Panamera 4S 971 (2016-2020) left static cornering light Wiring diagrams
This page contains all the electrical diagrams for the component. left static cornering light, in which he is found in the car Porsche Panamera 4S 971 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left static cornering light (1 of 2)
ANODE
ANODE CHANNEL 1
BLK WIRE
BLU WIRE
BRN WIRE
CAN HIGH
CAN LOW
CATHODE
CATHODE CHANNEL 1
CHANNEL
CODING PIN
FUSE 2
FUSE CARRIER 7
HEADLIGHTS MOTOR 1 -
HEADLIGHTS MOTOR 2 +
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LED A
LED ANODE
LED CATHODE
LED K
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 1
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 2
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 3
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 4
LEFT END-OUTLINE MARKER LAMP BULB 3
LEFT NUMBER PLATE LIGHT
LEFT STATIC CORNERING LIGHT
MTR 1 -
MTR 2 -
NEGATIVE
POSITIVE
R/L DETECTION
RED/BLK WIRE
RED/YEL WIRE
RIGHT DYNAMIC CORNERING LIGHT CONTROL MOTOR
RIGHT LED HEADLIGHT OUTPUT MODULE 2
RIGHT NUMBER PLATE LIGHT
RIGHT SEAT FUSE BOX
RIGHT TAILGATE GROUND POINT
SIGNAL
TERM 30
TERM 31
THERM PROT
Go to component -> Exterior lamps circuit, w/ led headlights (2 of 4) -> LEFT STATIC CORNERING LIGHT
Wiring diagram left static cornering light (2 of 2)
BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
CAN HIGH
CAN L
CAN LOW CHANNEL 3 ANODE
CAN-H
CHANNEL
CHANNEL 1
CHANNEL 1 CATHODE
CHANNEL 2 ANODE
CHANNEL 3 CHANNEL 3 CATHODE
CODING PIN
COMPUTER DATA LINES SYSTEM
ELECTROMECHANICAL PARKING BRAKE BUTTON
ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT
FLEXRAY 1- INPUT
FUN DISPLAY
FUN IND
FUSE 12
FUSE HOLDER A
GND LCM
GND LCM (HSS)
GND LED
GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
KL 30
KL 31
LED A
LED ANODE
LED CATHODE
LED K
LEFT ADDITIONAL MAIN BEAM BULB
LEFT DASHBOARD FUSE HOLDER
LEFT END-OUTLINE MARKER LAMP BULB 2
LEFT FRONT HEADLIGHT
LEFT LED HEADLIGHT FAN POWER MODULE
LEFT LED HEADLIGHT OUTPUT MODULE 1
LEFT STATIC CORNERING LIGHT
LIN 1 (RAIN/LIGHT SENSOR)
LIN 1 (ROTARY LIGHT SWITCH)
ONBOARD SUPPLY CONTROL UNIT
PNK WIRE
RED/BLK WIRE
ROTARY LIGHT SWITCH
SIGNAL
SIGNAL - CHANNEL 2 CATHODE
SIGNAL 1
SIGNAL 2
SIGNAL 3
SIGNAL 4 CHANNEL 1 ANODE
SIGNAL 5
SIGNAL 6
SIGNAL 7
SUPPLY
SWITCH 1
SWITCH 2
SWITCH 3
SWITCH 4
TERM 15 (CHANNEL 2)
TERM 15 (DRIVER IDENTIFICATION) FAN 1 SUPPLY
TERM 30
TERM 31
TERM 58 S
THERM PROT
VIO/WHT WIRE
Go to component -> Headlights circuit, w/ led headlights (1 of 6) -> LEFT STATIC CORNERING LIGHT
