Porsche Panamera 4S 971 (2016-2020) left rear seat adjustment operating unit Wiring diagram
This page shows the only wiring diagram for the component.left rear seat adjustment operating unit, which is found in the car Porsche Panamera 4S 971 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear seat adjustment operating unit (1 of 1)
BACK BACKREST
BACK SEAT DEPTH
BACKREST ANG ADJ BUTTON
BRN WIRE
CAN HIGH
CAN LOW
CODING PIN (DS-PS)
COMPUTER DATA LINES SYSTEM
FUSE 12
FUSE CARRIER 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT REAR MASSAGE SEAT CONTROL UNIT
LEFT REAR SEAT ADJUSTMENT OPERATING UNIT
LEFT SEAT FUSE BOX
LIN 2
LUMBAR FORWARD/BACK
LUMBAR HIGH LOW
ORG/BRN WIRE
ORG/GRN WIRE
POSITIVE
PUMP
REAR DRIVER SIDE MULTICONTOUR SEAT COMPRESSOR
REAR DRIVER SIDE MULTICONTOUR SEAT CONTROL UNIT
RED WIRE
SEAT DEPTH ADJ BUTTON
SECOND ROW LEFT SEAT CONTROL UNIT
TERM 30
TERM 30 SWITCHED
TERM 30 VALVES
TERM 31
TERM 31 VALVES
VIO/GRY WIRE
WHT/GRY WIRE
WHT/YEL WIRE
Go to component -> Left rear memory seat circuit (1 of 2) -> LEFT REAR SEAT ADJUSTMENT OPERATING UNIT
