Porsche Panamera 4S 971 (2016-2020) left potentiometer sig Wiring diagram
This page shows the only wiring diagram for the component.left potentiometer sig, which is found in the car Porsche Panamera 4S 971 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left potentiometer sig (1 of 1)
2.9L TWIN TURBO HYBRID, 4.0L TWIN TURBO HYBRID
ACTUATOR MOTOR GROUND
AIR CONDITIONING SYSTEM CONTROL UNIT
BLK/BLU WIRE
BLOWER CENTER VENT LEFT
BLOWER CENTER VENT RIGHT
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/YEL WIRE
CAN HI
CAN LO
CENTER VENT CONTROL MOTOR
COMPUTER DATA LINES SYSTEM
FUSE 8
FUSE 9
FUSE CARRIER 5
FUSE HOLDER B
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED
LED
LEFT CENTER VENT CONTROL MOTOR
LEFT FRONT CHEST VENT TEMPERATURE SENSOR
LEFT FRONT SIDE VENT CONTROL MOTOR
LEFT POTENTIOMETER SIG
LEFT REAR CENTER VENT CONTROL MOTOR 1
LEFT SIDE VENT BLOWER
LIN 3
LIN 4
LIN 5
LIN INPUT
LIN OUTPUT
MIDDLE REAR CENTER VENT CONTROL MOTOR 2
ORG/BRN WIRE
ORG/WHT WIRE
POTENTIOMETER
POTENTIOMETER SUPPLY
REAR IONISER 2
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT CENTER VENT CONTROL MOTOR
RIGHT DASHBOARD FUSE HOLDER
RIGHT FRONT SIDE VENT CONTROL MOTOR
RIGHT REAR AIR DISTRIBUTION CONTROL MOTOR 2
RIGHT REAR CENTER VENT CONTROL MOTOR 3
RIGHT SEAT FUSE BOX
RIGHT SIDE VENT BLOWER
SEATS SYSTEM
TERM 15
TERM 30
TERM 31
VIO/WHT WIRE
VIO/YEL WIRE
Go to component -> Automatic a/c circuit (1 of 8) -> LEFT POTENTIOMETER SIG
