Porsche Panamera 4S 971 (2016-2020) left led headlight output module 1 Wiring diagrams
This page contains all the electrical diagrams for the component. left led headlight output module 1, in which he is found in the car Porsche Panamera 4S 971 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left led headlight output module 1 (1 of 2)
ANODE CHANNEL 1
AREA LIGHTING
BLK WIRE
BRAKE LIGHT OUTPUT
BRAKE LIGHT SWITCH
BRN WIRE
BRN/GRY WIRE
CAN HIGH
CAN L
CAN LOW
CAN-H
CATHODE CHANNEL 1
CHANNEL
CHANNEL 1 CATHODE
CHANNEL 2 ANODE
CODING PIN
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL UNIT
DRIVER SIDE AUTOMATIC ANTI-DAZZLE EXTERIOR MIRROR
DRIVER SIDE EXTERIOR MIRROR LANE CHANGE ASSIST WARNING LAMP
DRIVER SIDE HEATED EXTERIOR MIRROR
DRIVER SIDE TURN SIGNAL REPEATER BULB
FUSE 2
FUSE HOLDER F
GND LCM
GND LED
HEADLIGHTS MOTOR 1 -
HEADLIGHTS MOTOR 2 +
HEADLIGHTS SYSTEM
HOT W/ MAIN RELAY ENERGIZED
LCA LED -
LED A
LED ANODE
LED CATHODE
LED K
LEFT ADDITIONAL MAIN BEAM BULB
LEFT DYNAMIC CORNERING LIGHT CONTROL MOTOR
LEFT END-OUTLINE MARKER LAMP BULB 1
LEFT END-OUTLINE MARKER LAMP BULB 2
LEFT FRONT FLASHING LIGHT
LEFT FRONT HEADLIGHT
LEFT LED HEADLIGHT OUTPUT MODULE 1
LEFT LED HEADLIGHT OUTPUT MODULE 2
MIRROR
MIRROR COURTESY LIGHT
MIRROR DIRECTION IND
MTR 1 -
MTR 2 -
NEGATIVE
ORG/BRN WIRE
ORG/GRN WIRE
POSITIVE
R/L DETECTION
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RIGHT ENGINE COMPARTMENT FUSE BOX
SIGNAL
SIGNAL - CHANNEL 2 CATHODE
SIGNAL 3
SIGNAL 5
SIGNAL 6 CHANNEL 1
STOP LIGHT SWITCH
TERM 30
TERM 31
TERM 87
THERM PROT
TRAILER DETECTOR CONTROL UNIT
Go to component -> Exterior lamps circuit, w/ led headlights (1 of 4) -> LEFT LED HEADLIGHT OUTPUT MODULE 1
Wiring diagram left led headlight output module 1 (2 of 2)
BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
CAN HIGH
CAN L
CAN LOW CHANNEL 3 ANODE
CAN-H
CHANNEL
CHANNEL 1
CHANNEL 1 CATHODE
CHANNEL 2 ANODE
CHANNEL 3 CHANNEL 3 CATHODE
CODING PIN
COMPUTER DATA LINES SYSTEM
ELECTROMECHANICAL PARKING BRAKE BUTTON
ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT
FLEXRAY 1- INPUT
FUN DISPLAY
FUN IND
FUSE 12
FUSE HOLDER A
GND LCM
GND LCM (HSS)
GND LED
GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
KL 30
KL 31
LED A
LED ANODE
LED CATHODE
LED K
LEFT ADDITIONAL MAIN BEAM BULB
LEFT DASHBOARD FUSE HOLDER
LEFT END-OUTLINE MARKER LAMP BULB 2
LEFT FRONT HEADLIGHT
LEFT LED HEADLIGHT FAN POWER MODULE
LEFT LED HEADLIGHT OUTPUT MODULE 1
LEFT STATIC CORNERING LIGHT
LIN 1 (RAIN/LIGHT SENSOR)
LIN 1 (ROTARY LIGHT SWITCH)
ONBOARD SUPPLY CONTROL UNIT
PNK WIRE
RED/BLK WIRE
ROTARY LIGHT SWITCH
SIGNAL
SIGNAL - CHANNEL 2 CATHODE
SIGNAL 1
SIGNAL 2
SIGNAL 3
SIGNAL 4 CHANNEL 1 ANODE
SIGNAL 5
SIGNAL 6
SIGNAL 7
SUPPLY
SWITCH 1
SWITCH 2
SWITCH 3
SWITCH 4
TERM 15 (CHANNEL 2)
TERM 15 (DRIVER IDENTIFICATION) FAN 1 SUPPLY
TERM 30
TERM 31
TERM 58 S
THERM PROT
VIO/WHT WIRE
Go to component -> Headlights circuit, w/ led headlights (1 of 6) -> LEFT LED HEADLIGHT OUTPUT MODULE 1
