Porsche Panamera 4S 971 (2016-2020) left headlight range control motor Wiring diagram
This page shows the only wiring diagram for the component.left headlight range control motor, which is found in the car Porsche Panamera 4S 971 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left headlight range control motor (1 of 1)
5 V SUPPLY SENSOR
AIR HUMIDITY RAIN, LIGHT SENSOR
ANODE CHANNEL 1
BLK WIRE
BRN WIRE
CAN HIGH
CAN LOW
CATHODE CHANNEL 1
CHANNEL
CODING 1
CODING PIN
CODING PIN CHANNEL 1
FUSE 2
FUSE CARRIER 3
GND SENSORS
HEADLIGHT VERTICAL CTRL MTR 1 -
HEADLIGHT VERTICAL CTRL MTR 2 -
HEADLIGHTS MOTOR 1 -
HEADLIGHTS MOTOR 2 +
HOT AT ALL TIMES
LED A
LED ANODE
LED CATHODE
LED K
LEFT DYNAMIC CORNERING LIGHT CONTROL MOTOR
LEFT END-OUTLINE MARKER LAMP BULB 1
LEFT END-OUTLINE MARKER LAMP BULB 3
LEFT HEADLIGHT RANGE CONTROL MOTOR
LEFT HEADLIGHT TEMPERATURE SENDER 1
LEFT LED HEADLIGHT OUTPUT MODULE 2
LEFT LED HEADLIGHT OUTPUT MODULE 4
LEFT SEAT FUSE BOX
MOTOR 1
MOTOR 2
MTR 1 -
MTR 2 -
NTC CHANNEL 1
POSITION SENSOR
PWM OUTPUT MODULE 3
R/L DETECTION
RED WIRE
SIGNAL
TEMP SENS
TERM 15
TERM 30
TERM 31
THERM PROT
VIO/WHT WIRE
Go to component -> Headlights circuit, w/ led headlights (2 of 6) -> LEFT HEADLIGHT RANGE CONTROL MOTOR
