Porsche Panamera 4S 971 (2016-2020) left front side vent control motor Wiring diagrams
This page contains all the electrical diagrams for the component. left front side vent control motor, in which he is found in the car Porsche Panamera 4S 971 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front side vent control motor (1 of 2)
2.9L TWIN TURBO HYBRID, 4.0L TWIN TURBO HYBRID
ACTUATOR MOTOR GROUND
AIR CONDITIONING SYSTEM CONTROL UNIT
BLK/BLU WIRE
BLOWER CENTER VENT LEFT
BLOWER CENTER VENT RIGHT
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/YEL WIRE
CAN HI
CAN LO
CENTER VENT CONTROL MOTOR
COMPUTER DATA LINES SYSTEM
FUSE 8
FUSE 9
FUSE CARRIER 5
FUSE HOLDER B
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED
LED
LEFT CENTER VENT CONTROL MOTOR
LEFT FRONT CHEST VENT TEMPERATURE SENSOR
LEFT FRONT SIDE VENT CONTROL MOTOR
LEFT POTENTIOMETER SIG
LEFT REAR CENTER VENT CONTROL MOTOR 1
LEFT SIDE VENT BLOWER
LIN 3
LIN 4
LIN 5
LIN INPUT
LIN OUTPUT
MIDDLE REAR CENTER VENT CONTROL MOTOR 2
ORG/BRN WIRE
ORG/WHT WIRE
POTENTIOMETER
POTENTIOMETER SUPPLY
REAR IONISER 2
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT CENTER VENT CONTROL MOTOR
RIGHT DASHBOARD FUSE HOLDER
RIGHT FRONT SIDE VENT CONTROL MOTOR
RIGHT REAR AIR DISTRIBUTION CONTROL MOTOR 2
RIGHT REAR CENTER VENT CONTROL MOTOR 3
RIGHT SEAT FUSE BOX
RIGHT SIDE VENT BLOWER
SEATS SYSTEM
TERM 15
TERM 30
TERM 31
VIO/WHT WIRE
VIO/YEL WIRE
Go to component -> Automatic a/c circuit (1 of 8) -> LEFT FRONT SIDE VENT CONTROL MOTOR
Wiring diagram left front side vent control motor (2 of 2)
ADDITIONAL INSTRUMENTS
AIR CONDITIONING SYSTEM CONTROL UNIT
AUTOMATIC HEATER CONTROL INTERIOR SENSOR
BLUETOOTH MOBILE PHONE COUPLING AERIAL
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/YEL WIRE
CENTER CONSOLE FRONT CIGAR LIGHTER
CENTRAL REAR VENT ILLUMINATION BULB
DRIVER SIDE KNEE AIR BAG IGNITER
ELECTROMECHANICAL PARKING BRAKE BUTTON
ENGINE SOUND GENERATOR CONTROL UNIT 2
FRESH AIR BLOWER
FRONT CENTER CONSOLE 12 V SOCKET 2
FRONT IONISER 1
FRONT PASSENGER AIR BAG UNIT
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER SIDE AIR BAG IGNITER
FRONT PASSENGER SIDE CENTRAL LOCKING LOCK UNIT
FRONT PASSENGER SIDE KNEE AIR BAG IGNITER
FRONT PASSENGER SIDE LIGHT SILL PANEL MOULDING AMBIENT LIGHTING
GLOVE COMPARTMENT LIGHT SWITCH
LEFT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2
LEFT FRONT CHEST VENT TEMPERATURE SENSOR
LEFT FRONT FOOTWELL LIGHT 1
LEFT FRONT FOOTWELL LIGHT 2
LEFT FRONT SIDE VENT CONTROL MOTOR
LEFT REAR FOOTWELL VENT TEMPERATURE SENDER
MOBILE TELEPHONE AERIAL AMPLIFIER
MULTIMEDIA SYSTEM OPERATING UNIT 2
NIGHT VISION SYSTEM CONTROL UNIT
REAR AIR CONDITIONING SYSTEM OPERATING, DISPLAY UNIT
REAR CENTER CONSOLE 12 V SOCKET 3
RIGHT FRONT CENTER CONSOLE BACKGROUND LIGHTING 3
RIGHT FRONT CHEST VENT TEMPERATURE SENSOR
RIGHT FRONT EXTERIOR DOOR HANDLE CONTACT SENSOR
RIGHT FRONT FOOTWELL LIGHT 1
RIGHT FRONT FOOTWELL LIGHT 2
RIGHT FRONT SIDE VENT CONTROL MOTOR
RIGHT PEDESTRIAN PROTECTION TRIGGER 2
RIGHT REAR FOOTWELL VENT TEMPERATURE SENDER
STRUCTURE-BORNE SOUND CONTROL UNIT
SUNLIGHT PENETRATION PHOTO SENSOR
USB CHARGING SOCKET 1
W/O BUSINESS PACKAGE
Go to component -> Ground distribution circuit (5 of 6) -> LEFT FRONT SIDE VENT CONTROL MOTOR
