Porsche Panamera 4S 971 (2016-2020) left front center console background lighting 2 Wiring diagrams
This page contains all the electrical diagrams for the component. left front center console background lighting 2, in which he is found in the car Porsche Panamera 4S 971 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front center console background lighting 2 (1 of 2)
ADDITIONAL INSTRUMENTS
AIR CONDITIONING SYSTEM CONTROL UNIT
AUTOMATIC HEATER CONTROL INTERIOR SENSOR
BLUETOOTH MOBILE PHONE COUPLING AERIAL
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/YEL WIRE
CENTER CONSOLE FRONT CIGAR LIGHTER
CENTRAL REAR VENT ILLUMINATION BULB
DRIVER SIDE KNEE AIR BAG IGNITER
ELECTROMECHANICAL PARKING BRAKE BUTTON
ENGINE SOUND GENERATOR CONTROL UNIT 2
FRESH AIR BLOWER
FRONT CENTER CONSOLE 12 V SOCKET 2
FRONT IONISER 1
FRONT PASSENGER AIR BAG UNIT
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER SIDE AIR BAG IGNITER
FRONT PASSENGER SIDE CENTRAL LOCKING LOCK UNIT
FRONT PASSENGER SIDE KNEE AIR BAG IGNITER
FRONT PASSENGER SIDE LIGHT SILL PANEL MOULDING AMBIENT LIGHTING
GLOVE COMPARTMENT LIGHT SWITCH
LEFT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2
LEFT FRONT CHEST VENT TEMPERATURE SENSOR
LEFT FRONT FOOTWELL LIGHT 1
LEFT FRONT FOOTWELL LIGHT 2
LEFT FRONT SIDE VENT CONTROL MOTOR
LEFT REAR FOOTWELL VENT TEMPERATURE SENDER
MOBILE TELEPHONE AERIAL AMPLIFIER
MULTIMEDIA SYSTEM OPERATING UNIT 2
NIGHT VISION SYSTEM CONTROL UNIT
REAR AIR CONDITIONING SYSTEM OPERATING, DISPLAY UNIT
REAR CENTER CONSOLE 12 V SOCKET 3
RIGHT FRONT CENTER CONSOLE BACKGROUND LIGHTING 3
RIGHT FRONT CHEST VENT TEMPERATURE SENSOR
RIGHT FRONT EXTERIOR DOOR HANDLE CONTACT SENSOR
RIGHT FRONT FOOTWELL LIGHT 1
RIGHT FRONT FOOTWELL LIGHT 2
RIGHT FRONT SIDE VENT CONTROL MOTOR
RIGHT PEDESTRIAN PROTECTION TRIGGER 2
RIGHT REAR FOOTWELL VENT TEMPERATURE SENDER
STRUCTURE-BORNE SOUND CONTROL UNIT
SUNLIGHT PENETRATION PHOTO SENSOR
USB CHARGING SOCKET 1
W/O BUSINESS PACKAGE
Go to component -> Ground distribution circuit (5 of 6) -> LEFT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2
Wiring diagram left front center console background lighting 2 (2 of 2)
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
ELECTRIC HINGED TOW COUPLING ATTACHMENT BUTTON
GRY/YEL WIRE
LEFT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2
LEFT FRONT FOOTWELL LIGHT 1
LEFT FRONT FOOTWELL LIGHT 2
LEFT LUGGAGE COMPARTMENT LIGHT
LEFT TAILGATE GROUND POINT 2
LIN INPUT
LIN OUTPUT
POSITIVE
REAR LID LIGHT
REAR LID LIGHT 2
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT CENTER CONSOLE BACKGROUND LIGHTING 3
RIGHT FRONT FOOTWELL LIGHT 1
RIGHT FRONT FOOTWELL LIGHT 2
RIGHT LUGGAGE COMPARTMENT LIGHT
RIGHT TAILGATE GROUND POINT
SIG
SWITCHED
TERM 30
TERM 31
TERM 31 BUTTON
TERM 58 S
TRAILER DETECTOR CONTROL UNIT
VIO/BLK WIRE
VIO/BLU WIRE
VIO/WHT WIRE
WHT/YEL WIRE
Go to component -> Interior lights circuit (2 of 7) -> LEFT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2
