Porsche Panamera 4S 971 (2016-2020) left daytime running light, side light led module 1 Wiring diagrams
This page contains all the electrical diagrams for the component. left daytime running light, side light led module 1, in which he is found in the car Porsche Panamera 4S 971 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left daytime running light, side light led module 1 (1 of 2)
ANODE
ANODE CHANNEL 1
BLK WIRE
BLU WIRE
BRN WIRE
CAN HIGH
CAN LOW
CATHODE
CATHODE CHANNEL 1
CHANNEL
CODING PIN
FUSE 2
FUSE CARRIER 7
HEADLIGHTS MOTOR 1 -
HEADLIGHTS MOTOR 2 +
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LED A
LED ANODE
LED CATHODE
LED K
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 1
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 2
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 3
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 4
LEFT END-OUTLINE MARKER LAMP BULB 3
LEFT NUMBER PLATE LIGHT
LEFT STATIC CORNERING LIGHT
MTR 1 -
MTR 2 -
NEGATIVE
POSITIVE
R/L DETECTION
RED/BLK WIRE
RED/YEL WIRE
RIGHT DYNAMIC CORNERING LIGHT CONTROL MOTOR
RIGHT LED HEADLIGHT OUTPUT MODULE 2
RIGHT NUMBER PLATE LIGHT
RIGHT SEAT FUSE BOX
RIGHT TAILGATE GROUND POINT
SIGNAL
TERM 30
TERM 31
THERM PROT
Go to component -> Exterior lamps circuit, w/ led headlights (2 of 4) -> LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 1
Wiring diagram left daytime running light, side light led module 1 (2 of 2)
5 V SUPPLY
ANODE
BLK WIRE
CATHODE
LED A
LED ANODE
LED CATHODE
LED K
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 1
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 2
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 3
LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 4
LEFT LED HEADLIGHT OUTPUT MODULE 3
LEFT LED HEADLIGHT OUTPUT MODULE 5
LEFT SWIVEL MODULE POSITION SENSOR
MOTOR 1
MOTOR 2
MOTOR GND
NCA WIRE
PWM
SENS GND
SUPPLY
TERM 31
Go to component -> Headlights circuit, w/ led headlights (3 of 6) -> LEFT DAYTIME RUNNING LIGHT, SIDE LIGHT LED MODULE 1
