Porsche Panamera 4S 971 (2016-2020) left center reading light Wiring diagram
This page shows the only wiring diagram for the component.left center reading light, which is found in the car Porsche Panamera 4S 971 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left center reading light (1 of 1)
AMBIENT LIGHT LIN
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DRIVER DOOR AMBIENT LIGHTING 3
FRONT ROOF MODULE
GRN WIRE
GRN/VIO WIRE
LED SUPPLY
LEFT CENTER READING LIGHT
LEFT REAR DOOR BACKGROUND LIGHTING 1
LEFT REAR FOOTWELL LIGHT
LIN INPUT
LR READING LIGHT
LR READING LIGHT BUTTON
PASSENGER DOOR AMBIENT LIGHTING 3
RED WIRE
RED/VIO WIRE
RIGHT CENTER READING LIGHT
RIGHT REAR DOOR BACKGROUND LIGHTING 1
RIGHT REAR FOOTWELL LIGHT
RR READING LIGHT
RR READING LIGHT BUTTON
TERM 30
TERM 30 SWITCHED
TERM 31
TERMINAL 30 SUNROOF
TERMINAL 58 S
VIO/BLK WIRE
VIO/BLU WIRE
VIO/WHT WIRE
WHT/YEL WIRE
Go to component -> Interior lights circuit (4 of 7) -> LEFT CENTER READING LIGHT
