Porsche Panamera 4S 971 (2016-2020) heater element crankcase breather intake pipe bank 1 Wiring diagram
This page shows the only wiring diagram for the component.heater element crankcase breather intake pipe bank 1, which is found in the car Porsche Panamera 4S 971 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heater element crankcase breather intake pipe bank 1 (1 of 1)
BRN/BLU WIRE
CONTINUED COOLANT CIRCULATION PUMP
CRANKCASE BREATHER HEATER ELEMENT 2
CRANKCASE BREATHER HEATER ELEMENT 3
CRANKCASE BREATHER VALVE
CYLINDER 2 SHUT-OFF EXHAUST DEACTIVATION VALVE
CYLINDER 2 SHUT-OFF INLET DEACTIVATION VALVE
CYLINDER 3 SHUT-OFF EXHAUST DEACTIVATION VALVE
CYLINDER 3 SHUT-OFF INLET DEACTIVATION VALVE
CYLINDER 5 SHUT-OFF EXHAUST DEACTIVATION VALVE
CYLINDER 5 SHUT-OFF INLET DEACTIVATION VALVE
CYLINDER 8 SHUT-OFF EXHAUST DEACTIVATION VALVE
CYLINDER 8 SHUT-OFF INLET DEACTIVATION VALVE
FROM RIGHT ENGINE COMPARTMENT FUSE BOX (DIAGRAM 4 OF 11)
FROM RIGHT ENGINE COMPARTMENT FUSE BOX (DIAGRAM 9 OF 11)
FROM RIGHT FRONT FUSE BOX (DIAGRAM 3 OF 11)
HEATER ELEMENT CRANKCASE BREATHER INTAKE PIPE BANK 1
IGNITION COIL 1 (W/ OUTPUT STAGE)
IGNITION COIL 2 (W/ OUTPUT STAGE)
IGNITION COIL 3 (W/ OUTPUT STAGE)
IGNITION COIL 4 (W/ OUTPUT STAGE)
IGNITION COIL 5 (W/ OUTPUT STAGE)
IGNITION COIL 6 (W/ OUTPUT STAGE)
LEFT FRONT SEAT BACKREST FAN 1
LEFT FRONT SEAT CUSHION FAN 1
LEFT REAR SEAT BACKREST FAN 1
LEFT REAR SEAT CUSHION FAN 1
MAP-CONTROLLED ENGINE COOLING SYSTEM THERMOSTAT
OVERRUN AIR RECIRCULATION VALVE BANK 1
OVERRUN AIR RECIRCULATION VALVE BANK 2
PISTON COOLING JET CONTROL VALVE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
TANK BREATHER VALVE
TANK BREATHER VALVE 2
WHT WIRE
Go to component -> Power distribution circuit (10 of 11) -> HEATER ELEMENT CRANKCASE BREATHER INTAKE PIPE BANK 1
