Porsche Panamera 4S 971 (2016-2020) hall sender 2 camshaft sensor intake 2 Wiring diagrams

This page contains all the electrical diagrams for the component. hall sender 2 camshaft sensor intake 2, in which he is found in the car Porsche Panamera 4S 971 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram hall sender 2 camshaft sensor intake 2 (1 of 3)

Wiring diagram hall sender 2 camshaft sensor intake 2 for Porsche Panamera 4S 971 (2016-2020) (1 of 3)

Get access

3.0L TURBO, 2.9L TWIN TURBO ACTUATION BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRY WIRE BLU WIRE BLU/GRY WIRE BOOST PRESS ADJ WASTEGATE 1 BOOST PRESS ADJ WASTEGATE 2 BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CHARGE AIR TEMP 1 - CHARGE AIR TEMP 2 CHARGE PRESSURE POSITIONER TRANSDUCER WASTEGATE COOLANT TEMP ENGINE OUTLET DIVERTER VLV 1 DIVERTER VLV 2 ENGINE CONTROL UNIT (LEFT REAR OF ENGINE COMPT) ENGINE COVER PANEL COMPARTMENT TEMPERATURE SENDER ENGINE OUTLET COOLANT TEMPERATURE SENDER FUEL INJ 1 FUEL INJ 3 FUEL INJ 6 FUEL METERING VALVE GND POTI GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/RED WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HALL SENDER HALL SENDER 2 CAMSHAFT SENSOR INTAKE 2 HALL SENDER 3 CAMSHAFT SENSOR EXHAUST 1 HALL SENDER 4 CAMSHAFT SENSOR EXHAUST 2 HIGH PRESS PUMP FLOW CTRL VLV - INJECTOR CYLINDER 1 INJECTOR CYLINDER 6 INTAKE CAMSHAFT SENS BANK 1 - INTAKE CAMSHAFT SENS BANK 2 - MOTOR OUTLET CAMSHAFT SENS BANK 1 - OUTLET CAMSHAFT SENS BANK 2 - OVERRUN AIR RECIRCULATION BANK 1 VALVE OVERRUN AIR RECIRCULATION VALVE BANK 2 POS RED WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SIG SIGNAL 1 SIGNAL 2 TANK BREATHER VALVE TANK VENT VLV 1 TANK VENT VLV 2 TEMP SENS CYL HEAD - TEMP SENS ON CRANKCASE - TEMP SENS ON ENGINE COVER - TEMPERATURE SENDER 1 CHARGE AIR COOLER ENGINE COMPARTMENT TEMPERATURE SENDER 2 CHARGE AIR COOLER ENGINE COMPARTMENT THROTTLE VALVE MODULE THROTTLE VLV ACTUAL 1 THROTTLE VLV ACTUAL 2 THROTTLE VLV GND THROTTLE VLV MOTOR + VIO WIRE VIO/BLU WIRE VIO/YEL WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE YEL/VIO WIRE

Go to component -> Wiring diagram engine performance 2.9l twin turbo (8 of 8) -> HALL SENDER 2 CAMSHAFT SENSOR INTAKE 2
