Porsche Panamera 4S 971 (2016-2020) glass roof output 1 mtr 1 Wiring diagram
This page shows the only wiring diagram for the component.glass roof output 1 mtr 1, which is found in the car Porsche Panamera 4S 971 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram glass roof output 1 mtr 1 (1 of 1)
BLK WIRE
BRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 8
FUSE CARRIER 3
FUSE CARRIER 7
GLASS ROOF OUTPUT 1 MTR 1
GLASS ROOF OUTPUT 1 MTR 2
GLASS ROOF OUTPUT 2 MTR 1
GLASS ROOF OUTPUT 2 MTR 2
GROUND
HALL 1 MOTOR 1
HALL 1 MOTOR 2
HALL 2 MOTOR 1
HALL 2 MOTOR 2
HALL SENSOR
HALL SENSOR SIG A
HALL SENSOR SIG B
HALL SENSOR SIGNAL A
HALL SENSOR SIGNAL B
HALL SENSOR SUPPLY
HOT AT ALL TIMES
LEFT SEAT FUSE BOX
LIFT
LOCATING LIGHT
MOTOR 1 OUTPUT A
MOTOR 1 OUTPUT B
NEGATIVE
ORG/BRN WIRE
ORG/GRN WIRE
REAR SLIDING SUNROOF CONTROL UNIT
RED WIRE
RIGHT SEAT FUSE BOX
ROLLER BLIND
ROOF ROLLER BLIND BUTTON 1
ROTARY VANE POSITION
SIGNAL
SIGNAL LIFT
SLIDING ROOF
SLIDING SUNROOF ADJUSTMENT CONTROL UNIT
SLIDING SUNROOF MOTOR
SUNROOF ROLLER BLIND MOTOR
SUNROOF ROLLER BLIND MOTOR 2
SUNROOF SWITCH
TERM 30
TERM 31
Go to component -> Power top/sunroof circuit -> GLASS ROOF OUTPUT 1 MTR 1
