Porsche Panamera 4S 971 (2016-2020) front anti-roll bar control unit Wiring diagrams
This page contains all the electrical diagrams for the component. front anti-roll bar control unit, in which he is found in the car Porsche Panamera 4S 971 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front anti-roll bar control unit (1 of 5)
ACCELERATOR PEDAL MODULE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAN DRIVE 1 HIGH
CAN DRIVE 1 LOW
CAN HI MIB
CAN HIGH
CAN LO MIB
CAN LOW
CRASH HIGH
CRASH LOW
DRIVE HIGH
DRIVE LOW
ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT
ENGINE CONTROL UNIT
ENGINE SOUND GENERATOR CONTROL UNIT 2
FLEXRAY 1- INPUT
FLEXRAY 2- OUTPUT
FRONT ANTI-ROLL BAR CONTROL UNIT
FRONT CENTER CONSOLE OPERATING UNIT
GAS SUSPENSION COMPRESSOR
GRN WIRE
GRY/RED WIRE
MASTER LANE CHANGE ASSIST CONTROL UNIT
MMI HIGH
MMI LOW
MULTIMEDIA SYSTEM OPERATING, DISPLAY UNIT
NIGHT VISION SYSTEM CONTROL UNIT
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/RED WIRE
ORG/WHT WIRE
OVERHEAD VIEW CAMERA CONTROL UNIT
PNK WIRE
PRIVAT HIGH
PRIVAT LOW
REAR ANTI-ROLL BAR CONTROL UNIT 2
REVERSING CAMERA SYSTEM CONTROL UNIT
RIGHT FRONT SEAT ADJUSTER CONTROL UNIT
SLAVE LANE CHANGE ASSIST CONTROL UNIT 2
STRUCTURE-BORNE SOUND CONTROL UNIT
TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT
VIO/GRY WIRE
Go to component -> Computer data lines circuit (3 of 5) -> FRONT ANTI-ROLL BAR CONTROL UNIT
Wiring diagram front anti-roll bar control unit (2 of 5)
BLK/GRY WIRE
BRN WIRE
BRN/YEL WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
FRONT ANTI-ROLL BAR CONTROL UNIT
FUSE 3
FUSE 4
FUSE 6
FUSE 9
FUSE CARRIER 1
FUSE HOLDER C
FUSE HOLDER E
HOT AT ALL TIMES
HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED
LEFT SEAT FUSE BOX
MID FUSE 2
ORG/BLK WIRE
ORG/BRN WIRE
POTENTIAL EQUALISATION
REAR ANTI-ROLL BAR CONTROL UNIT 2
REAR FUSE BOX
RED WIRE
RED/BLU WIRE
TERM 15
TERM 15 COD VA
TERM 30
TERM 31
TERMINAL 40
TERMINAL 40 WIRING JUNCTION
TERMINAL 41
VIO WIRE
Go to component -> Dynamic chassis control circuit -> FRONT ANTI-ROLL BAR CONTROL UNIT
Wiring diagram front anti-roll bar control unit (3 of 5)
4.0L TURBO, 4.0L TWIN TURBO HYBRID
ADAPTIVE CRUISE CONTROL UNIT
ADAPTIVE CRUISE CONTROL UNIT 2
AIR CONDITIONING SYSTEM PRESSURE SWITCH
AIR QUALITY SENSOR
AUTOMATIC GLOW PERIOD CONTROL UNIT
BASS HORN
BLK WIRE
BONNET CONTACT SWITCH
BRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CHANGEOVER VALVE
CIRCULATION PUMP 2
CONTINUED COOLANT CIRCULATION PUMP
COOLANT CIRCULATION PUMP
COOLANT PUMP
ELECTRIC DRIVE POWER, CONTROL ELECTRONICS
ELECTRICAL HIGH VOLTAGE HEATER (PTC)
ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT
ENGINE CONTROL UNIT
FRONT ANTI-ROLL BAR CONTROL UNIT
GLOW PERIOD CONTROL UNIT 2
HEADLIGHT WASHER SYSTEM PUMP
HEATER COOLANT SHUT-OFF VALVE
IGNITION COIL 1 (W/ OUTPUT STAGE)
IGNITION COIL 2 (W/ OUTPUT STAGE)
IGNITION COIL 3 (W/ OUTPUT STAGE)
IGNITION COIL 4 (W/ OUTPUT STAGE)
IGNITION COIL 5 (W/ OUTPUT STAGE)
IGNITION COIL 6 (W/ OUTPUT STAGE)
IGNITION COIL 7 (W/ OUTPUT STAGE)
IGNITION COIL 8 (W/ OUTPUT STAGE)
LEFT FRONT HEADLIGHT
LEFT FRONT SIDE MARKER BULB
LEFT FRONT TURN SIGNAL, SIDE LIGHT BULB
LEFT PEDESTRIAN PROTECTION TRIGGER 1
LOW TEMPERATURE CIRCUIT COOLANT PUMP
LOW TEMPERATURE CIRCUIT COOLANT PUMP 2
RADIATOR BLIND CONTROL MOTOR
RIGHT ENGINE COMPARTMENT FUSE BOX
RIGHT FRONT HEADLIGHT
RIGHT FRONT SIDE MARKER BULB
RIGHT FRONT TURN SIGNAL, SIDE LIGHT BULB
TREBLE HORN
VIO/BRN WIRE
WATER PUMP RELAY
YEL WIRE
Go to component -> Ground distribution circuit (1 of 6) -> FRONT ANTI-ROLL BAR CONTROL UNIT
Wiring diagram front anti-roll bar control unit (4 of 5)
ACCELERATOR PEDAL MODULE
ADAPTIVE CRUISE CONTROL UNIT 3
ADAPTIVE SUSPENSION CONTROL UNIT
AUTOMATIC GEARBOX CONTROL UNIT
AXLE DIFFERENTIAL LOCK CONTROL UNIT
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
DATA BUS DIAGNOSTIC INTERFACE
DIAGNOSTIC CONNECTION
DVD CHANGER
ENGINE CONTROL UNIT
FROM MAIN FUSE BOX (DIAGRAM 1 OF 11)
FROM ONBOARD SUPPLY CONTROL UNIT 2 (DIAGRAM 2 OF 11)
FROM REAR FUSE BOX (DIAGRAM 1 OF 11)
FRONT ANTI-ROLL BAR CONTROL UNIT
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9 (HYBRID)
FUSE CARRIER 1
FUSE CARRIER 2
FUSE HOLDER E
GRN/VIO WIRE
HEATED REAR WINDOW RELAY
INTERIOR MIRROR
LEFT FRONT HEADLIGHT
LEFT SEAT FUSE BOX
MASTER ADAPTIVE CRUISE CONTROL UNIT
N/A
REAR ANTI-ROLL BAR CONTROL UNIT 2
REAR FUSE BOX
REAR WHEEL STEERING CONTROL UNIT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
SERVOTRONIC CONTROL UNIT
SLAVE ADAPTIVE CRUISE CONTROL UNIT 2
TERMINAL 15 VOLTAGE SUPPLY RELAY
TO RIGHT SEAT FUSE BOX (DIAGRAM 3 OF 11)
TRAILER DETECTOR CONTROL UNIT
WATER PUMP RELAY
Go to component -> Power distribution circuit (6 of 11) -> FRONT ANTI-ROLL BAR CONTROL UNIT
Wiring diagram front anti-roll bar control unit (5 of 5)
AIR BAG CONTROL UNIT
AIR HUMIDITY RAIN, LIGHT SENSOR
AUTOMATIC GEARBOX CONTROL UNIT
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRAKE SERVO CONTROL UNIT
DATA BUS DIAGNOSTIC INTERFACE
DRIVER DOOR CONTROL UNIT
FROM MAIN FUSE BOX (DIAGRAM 1 OF 11)
FRONT ANTI-ROLL BAR CONTROL UNIT
FRONT ROOF MODULE
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE CARRIER 1
FUSE CARRIER 2
FUSE CARRIER 3
LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
LEFT FRONT SEAT BELT
LEFT REAR DOOR CONTROL UNIT
LEFT REAR SMART DISPLAY CONTROL UNIT
LEFT SEAT FUSE BOX
N/A
ONBOARD SUPPLY CONTROL UNIT
REAR LID POWER OPENING CONTROL UNIT
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
SECOND ROW LEFT SEAT CONTROL UNIT
SIREN
SLIDING SUNROOF ADJUSTMENT CONTROL UNIT
TO LEFT DASHBOARD FUSE HOLDER (DIAGRAM 8 OF 11)
TO LEFT SEAT FUSE BOX (DIAGRAM 8 OF 11)
TRAILER DETECTOR CONTROL UNIT
W/ MEMORY
W/O MEMORY
Go to component -> Power distribution circuit (7 of 11) -> FRONT ANTI-ROLL BAR CONTROL UNIT
