Porsche Panamera 4S 971 (2016-2020) driver seat control unit ground Wiring diagrams
This page contains all the electrical diagrams for the component. driver seat control unit ground, in which he is found in the car Porsche Panamera 4S 971 (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver seat control unit ground (1 of 2)
BACKREST ANG ADJ BUTTON
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
CODING PIN (DS-PS)
COMPUTER DATA LINES SYSTEM
DRIVER MULTICONTOUR SEAT CONTROL UNIT
DRIVER SEAT CONTROL UNIT GROUND
DRIVER SEAT MULTICONTOUR COMPRESSOR
FRONT SEAT HEIGHT ADJ
FUSE 1
FUSE CARRIER 3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT MASSAGE SEAT CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
LEFT SEAT FUSE BOX
LIN 2
LUMBAR FORWARD/BACK
LUMBAR HIGH LOW
MESSAGE BUTTON
ORG/BRN WIRE
ORG/GRN WIRE
POSITIVE
PUMP
REAR SEAT HEIGHT ADJ
RED WIRE
RED/WHT WIRE
SEAT ANGLE ADJ BUTTON
SEAT BACKREST ADJ
SEAT BACKREST BOLSTER ADJ
SEAT CUSHION BOLSTER ADJ
SEAT CUSHION DEPTH ADJ
SEAT DEPTH ADJ BUTTON
SEAT F/A ADJ BUTTON
SEAT FORE, AFT ADJ
SEAT HEIGHT ADJ BUTTON
TERM 30
TERM 30 SWITCHED
TERM 30 VALVES
TERM 31
TERM 31 VALVES
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
VIO/YEL WIRE
WHT WIRE
YEL WIRE
Go to component -> Driver"s memory seat circuit (1 of 2) -> DRIVER SEAT CONTROL UNIT GROUND
Wiring diagram driver seat control unit ground (2 of 2)
ADAPTIVE CRUISE CONTROL UNIT 3
BRN WIRE
BRN/GRN WIRE
BRN/YEL WIRE
DATA BUS DIAGNOSTIC INTERFACE
DRIVER SEAT CONTROL UNIT GROUND
DRIVER SIDE AIR BAG IGNITER
DRIVER SIDE LIGHT REAR SILL PANEL MOULDING AMBIENT LIGHT
DRIVER SIDE LIGHT SILL PANEL MOULDING AMBIENT LIGHTING
DRIVER SIDE REAR AIR BAG IGNITER
INTERIOR MONITORING DEACTIVATION SWITCH
LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
LEFT FRONT SEAT BACKREST FAN 1
LEFT FRONT SEAT BELT
LEFT FRONT SEAT CUSHION FAN 1
LEFT FRONT SEAT EXTENSION HEATER ELEMENT
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATED CUSHION
LEFT REAR CENTRAL LOCKING LOCK UNIT
LEFT REAR DOOR CONTROL UNIT
LEFT REAR EXTERIOR DOOR HANDLE CONTACT SENSOR
LEFT REAR FOOTWELL LIGHT
LEFT REAR SEAT BACKREST FAN 1
LEFT REAR SEAT CUSHION FAN 1
LEFT REAR SEAT HEATED BACKREST
LEFT REAR SEAT HEATED BENCH CUSHION
LEFT REAR SEAT HEATING CONTROL UNIT
LEFT REAR SEAT LATERAL SUPPORT HEATER
LEFT REAR SMART DISPLAY CONTROL UNIT
LEFT REAR VENT ILLUMINATION BULB
SECOND ROW LEFT SEAT CONTROL UNIT
Go to component -> Ground distribution circuit (3 of 6) -> DRIVER SEAT CONTROL UNIT GROUND
