Porsche Panamera 4S 971 (2016-2020) burmester digital sound package amplifier Wiring diagrams

ADAPTIVE SUSPENSION CONTROL UNIT AUDIO, VIDEO ADDITIONAL CONNECTIONS UNIT AXLE DIFFERENTIAL LOCK CONTROL UNIT BATTERY CHARGE SELECTORS BUTTON MODULE BLK WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BURMESTER DIGITAL SOUND PACKAGE AMPLIFIER DIGITAL SOUND PACKAGE AMPLIFIER DVD CHANGER EXHAUST FLAP CONTROL UNIT EXHAUST FLAP CONTROL UNIT 2 FUEL DELIVERY UNIT FUEL PUMP CONTROL UNIT GARAGE DOOR OPERATION CONTROL UNIT GAS SUSPENSION COMPRESSOR HEATED REAR WINDOW RELAY HIGH VOLTAGE BATTERY CHARGING UNIT 1 HIGH VOLTAGE BATTERY COOLANT PUMP LANE CHANGE ASSIST CONTROL UNIT LANE CHANGE ASSIST CONTROL UNIT 2 LEFT LUGGAGE COMPARTMENT 12 V SOCKET 6 LEFT LUGGAGE COMPARTMENT LIGHT LEFT REAR BRAKE PAD WEAR SENDER LEFT TAILLIGHT MOBILE TELEPHONE AERIAL AMPLIFIER 2 MULTIMEDIA SYSTEM MULTIMEDIA SYSTEM OPERATING UNIT MULTIMEDIA SYSTEM OPERATING, DISPLAY UNIT ONBOARD SUPPLY CONTROL UNIT 2 OVERHEAD VIEW CAMERA CONTROL UNIT REAR ANTI-ROLL BAR CONTROL UNIT 2 REAR FUSE BOX REAR LID CLOSURE BUTTON REAR LID POWER OPENING CONTROL UNIT REAR SLIDING SUNROOF CONTROL UNIT REAR WHEEL STEERING CONTROL UNIT RIGHT LUGGAGE COMPARTMENT LIGHT RIGHT REAR SEAT LATERAL SUPPORT HEATER RIGHT TAILLIGHT TANK FILLER FLAP LOCKING MOTOR TERMINAL 15 VOLTAGE SUPPLY RELAY TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT TRAILER DETECTOR CONTROL UNIT WATER PUMP RELAY

1/+ BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/VIO WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE BURMESTER DIGITAL SOUND PACKAGE AMPLIFIER FRONT ROOF MODULE GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HI RANGE CENTER LOUDSPEAKER - HOT AT ALL TIMES LEFT EFFECT LOUDSPEAKER LEFT EFFECT SPEAKER 2 LEFT FRONT BASS LOUDSPEAKER LEFT REAR BASS LOUDSPEAKER LEFT REAR MID-RANGE/ LOUDSPEAKER LEFT REAR TREBLE LOUDSPEAKER LF LO RANGE SPKR - LF MID-RANGE LOUDSPEAKER - LF MID-RANGE TWEETER - LF TWEETER+ LR LO RANGE SPKR - LR MID-RANGE SPEAKER + LR MID-RANGE SPKR - LR SURROUND LOUDSPEAKER + LR TWEETER + LT HI RANGE LOUDSPEAKER - LT MID-RANGE LOUDSPEAKER - MAXI FUSE 5 MAXI FUSE 6 MICROPHONE MID-RANGE CENTER LOUDSPEAKER - REAR FUSE BOX RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 REMOTE SUBWOOFER RF LO RANGE SPKR - RF MID-RANGE LOUDSPEAKER - RF TWEETER - RIGHT EFFECT LOUDSPEAKER RIGHT FRONT BASS LOUDSPEAKER RING BREAK DIAGNOSIS RR LO RANGE SPKR - RR MID-RANGE SPEAKER + RR MID-RANGE SPKR - RR WIDE BAND SPKR TWEETER - RR WIDE-BAND SPKR - RT HI RANGE LOUDSPEAKER + MID-RANGE CENTER LOUDSPEAKER + RT HI RANGE LOUDSPEAKER - RT MID-RANGE LOUDSPEAKER - RT MID-RANGE WIDE-BAND SPKR + SOUND ACQUISITION MICROPHONE + SOUND SYSTEMS SUBWOOFER TERM 30 TERM 31 VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE YEL/VIO WIRE

BURMESTER DIGITAL SOUND PACKAGE AMPLIFIER DIGITAL SOUND PACKAGE AMPLIFIER DVD CHANGER GRN WIRE MOST IN MOST OUT MULTIMEDIA SYSTEM OPTICAL WAVEGUIDE IN OPTICAL WAVEGUIDE OUT RX MOST TX MOST W/ BOSE AMPLIFIER W/ BOSE AMPLIFIER, DVD CHANGER W/ BURMESTER AMPLIFIER W/ BURMESTER AMPLIFIER, DVD CHANGER W/ DVD CHANGER

AIR BAG CONTROL UNIT BATT + BATT SENS BATTERY BATTERY ISOLATION UNIT BATTERY MONITOR CONTROL UNIT BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRAKE SERVO CONTROL UNIT BURMESTER DIGITAL SOUND PACKAGE AMPLIFIER COMPUTER DATA LINES SYSTEM DIGITAL SOUND PACKAGE AMPLIFIER ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT FROM RIGHT FRONT FUSE BOX (DIAGRAM 3 OF 11) FUSE 1 FUSE 2 FUSE 3 FUSE 4 FUSE 5 (HYBRID) FUSE 6 FUSE 7 FUSE 8 FUSE CARRIER 8 GAS SUSPENSION COMPRESSOR GENERATOR GND LINE JUMP START CONNECTION MAIN FUSE BOX (LEFT SIDE OF TRUNK) MAXI FUSE 1 MAXI FUSE 2 MAXI FUSE 3 MAXI FUSE 4 MAXI FUSE 5 MAXI FUSE 6 N/A NCA WIRE RADIATOR FAN REAR FUSE BOX REAR WHEEL STEERING CONTROL UNIT RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 RIGHT FRONT SEAT BACKREST FAN 1 RIGHT FRONT SEAT CUSHION FAN 1 RIGHT REAR SEAT BACKREST FAN 1 RIGHT REAR SEAT CUSHION FAN 1 SERVOTRONIC CONTROL UNIT STARTER TERM 30 TO LEFT SEAT FUSE BOX (DIAGRAM 7 OF 11) TO REAR FUSE BOX (DIAGRAM 5 OF 11) TO REAR FUSE BOX (DIAGRAM 6 OF 11) TO RIGHT ENGINE COMPARTMENT FUSE BOX (DIAGRAM 4 OF 11) TO RIGHT FRONT FUSE BOX (DIAGRAM 3 OF 11) TO RIGHT SEAT FUSE BOX (DIAGRAM 2 OF 11) TRANSFER PIN K TRANSFER PIN L TRANSFER PIN M TRANSFER PIN N TRANSFER PIN P TRANSFER PIN R VIO/GRY WIRE W/ BURMESTER
