Porsche Panamera 4 970 facelift (2013-2016) Base radio circuit, w/o amplifier

AM/FM 1 AM/FM 1 SHIELD ANTENNA ANTENNA SPLY AUX GND AUX L + AUX R + AUX RTN AUX SHIELD BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CAN HIGH CAN LOW CENTRAL LCCK ANTENNA COMPUTER DATA LINES SYSTEM DC/DC CONVERTER 1 DRIVER'S DOOR MID-RANGE SPEAKER DRIVER'S DOOR WOOFER FM 2 FM 2 SHIELD FRONT BCM (UNDER LEFT SIDE OF DASH) FRONT PASSENGER DOOR WOOFER FRONT PASSENGER MID RANGE SPEAKER FUSE 3 FUSE 4 FZV GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE HF 1 SIG HF 2 SIG HOT AT ALL TIMES LEFT FRONT FUSE BOX LEFT LSP DASH BOARD LEFT REAR TWEETER LEFT REAR WOOFER LF SPEAKER (+) LR SPEAKER (+) MICROPHONE MICROPHONE 1 - MICROPHONE GND MICROPHONE SHIELD NEG O/P TERM 30-2 ORG/BRN WIRE ORG/VIO WIRE POS RADIO REAR FUSE BOX (ROW A) RED WIRE RED/BLK WIRE RED/YEL WIRE RELAY ENERGIZED RF SPEAKER (+) RIGHT ANTENNA AMPLIFIER RIGHT LSP DASH BOARD RIGHT REAR TWEETER RIGHT REAR WOOFER ROOF CONSOLE RR SPEAKER (+) SDARS ANTENNA SHIELD TERM 30 TERM 31 TV TUNER CIRCUIT UBATT UNIVERSAL AUDIO INTERFACE VIO WIRE VIO/BLK WIRE W/ START/STOP FUNCTION W/O START/STOP FUNCTION WAKE-UP WHT WIRE WHT/BLK WIRE YEL WIRE
