Power distribution circuit for Porsche Panamera 4 970 facelift (2013-2016)

ALARM SIREN AMPLIFIER ASK AMPLIFIER AUXILIARY HEATER TELESTART RECEIVER BATTERY BATTERY SENSOR BLK WIRE BOSE AMPLIFIER BRN WIRE BURMESTER AMPLIFIER CENTER CONSOLE CIGAR LIGHTER COOL BOX PREPARATION DIAGNOSTIC PLUG SOCKET DME RELAY 1 EXCEPT 3.0L HYBRID FROM MAIN FUSE BOX (DIAGRAM 1 OF 7) FRONT PASSENGER SEAT ADJUSTMENT OUTPUT CONTROL UNIT FUEL PUMP SYSTEM CONTROL UNIT FUSE 1 FUSE 2 FUSE 27 FUSE 28 FUSE 29 FUSE 3 FUSE 30 FUSE 31 FUSE 32 FUSE 38 FUSE 39 FUSE 4 FUSE 40 FUSE 41 FUSE 42 FUSE 43 FUSE 44 FUSE 45 FUSE 46 FUSE 47 FUSE 48 FUSE 49 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 9 FUSE HOLDER 1 GLOVE BOX PLUG SOCKET GRN WIRE GRY/RED WIRE HV CHARGER LEFT REAR SEAT ENTERTAINMENT MAIN FUSE BOX MAXI FUSE 57 PASSENGER'S DOOR CONTROL UNIT PLENUM PANEL FUSE BOX PSM CONTROL UNIT REAR CENTER CONSOLE PLUG SOCKET 1 REAR CENTER CONSOLE PLUG SOCKET 2 REAR CENTER CONSOLE PLUG SOCKET 3 RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT FUSE BOX RIGHT REAR DOOR CONTROL UNIT RIGHT REAR SEAT ENTERTAINMENT SOCKET RELAY STORAGE BIN CENTER CONSOLE SOCKET TERM 30 TERM 31 TO JUMP START POINT (DIAGRAM 7 OF 7) TO KL 15 RELAY (DIAGRAM 6 OF 7) TO LEFT FRONT FUSE BOX (DIAGRAM 2 OF 7) TO LEFT FRONT FUSE BOX (DIAGRAM 3 OF 7) TO LEFT FRONT FUSE BOX (DIAGRAM 4 OF 7) TO LEFT FRONT FUSE BOX (DIAGRAM 7 OF 7) TO MAXI FUSE (DIAGRAM 5 OF 7) TO REAR FUSE BOX (ROW A) (DIAGRAM 3 OF 7) TO REAR FUSE BOX (ROW A) (DIAGRAM 5 OF 7) TO RIGHT FRONT FUSE BOX (DIAGRAM 1 OF 7) TO RIGHT FRONT FUSE BOX (DIAGRAM 4 OF 7) TO RIGHT FRONT FUSE BOX (DIAGRAM 5 OF 7) TRANSPORT SWITCH TV TUNER TWO-TONE HORNS RELAY W/ BASIC W/ ASK W/ BURMESTER W/ BOSE W/ LARGE REAR CENTER CONSOLE W/O LARGE REAR CENTER CONSOLE W/O MEMORY WHT WIRE YEL WIRE

AIR CONDITIONING RELAY BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE CAN COMFORT HIGH CAN COMFORT LOW COMPUTER DATA LINES SYSTEM DME CONTROL UNIT DME RELAY 1 DRIVER FAN BLOWER REGULATOR DRIVER'S DOOR CONTROL UNIT ELECTRIC PARKING BRAKE BUTTON ELECTRONIC IGNITION LOCK EXCEPT HYBRID EXCEPT HYBRID HYBRID 3.6L, 4.8L, 4.8L TURBO 3.0L TURBO FROM DC/DC CONVERTER 1 (DIAGRAM 3 OF 7) FROM MAIN FUSE BOX (DIAGRAM 1 OF 7) FRONT BCM FRONT WIPER MOTOR FUSE 10 FUSE 11 FUSE 12 FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 26 FUSE 41 FUSE 42 FUSE 43 FUSE 47 FUSE 48 FUSE 49 FUSE 50 FUSE 57 FUSE 7 FUSE 8 FUSE 9 GRN WIRE GRY/BLU WIRE IGNITION LOCK SW 1 IGNITION LOCK SW 2 IGNITION LOCK SW 3 IGNITION LOCK SW 4 IGNITION LOCK SW 5 IGNITION LOCK SW 6 LEFT FRONT FUSE BOX LEFT REAR DOOR CONTROL UNIT LIN LOW TEMPERATURE CIRCUIT WATER PUMP RELAY, ACC CONTROL UNIT LOW TEMPERATURE WATER CIRCUIT CONTROL VALVE N/A ORG/BRN WIRE ORG/GRN WIRE PDK TRANSMISSION CONTROL UNIT PSM CONTROL UNIT RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE ROOF CONSOLE ROTARY LIGHT SWITCH SLIDING ROOF CONTROL UNIT STEERING COLUMN ADJUSTMENT CONTROL UNIT STEERING COLUMN LOCK SW 1 SW 2 SW 3 SW 4 SW 5 SW 6 TERM 30 TERM 31 TO RIGHT FRONT FUSE BOX (DIAGRAM 5 OF 7) TRANSMISSION CONTROL UNIT VIO WIRE WITHDRAWAL LOCK YEL/RED WIRE YEL/VIO WIRE

3.6L, 4.8L, 4.8L TURBO A/C CONTROL UNIT AFTER-RUN COOLANT PUMP AMPLIFIER ASK AMPLIFIER BACKUP CAMERA CONTROL UNIT BASE RADIO BLK/BLU WIRE BLK/GRN WIRE BOSE AMPLIFIER BRN WIRE DC/DC CONVERTER 1 (W/ START/STOP FUNCTION) DIAGNOSTICS 1 DIAGNOSTICS 2 DRIVER'S SEAT CONTROL UNIT EXCEPT HYBRID EXCEPT HYBRID W/ ASK W/ BASE FROM DC/DC CONVERTER 1 (DIAGRAM 3 OF 7) FROM MAIN FUSE BOX (DIAGRAM 1 OF 7) FUSE 1 FUSE 10 FUSE 11 FUSE 12 FUSE 2 FUSE 3 FUSE 4 FUSE 5 FUSE 51 FUSE 52 FUSE 53 FUSE 54 FUSE 55 FUSE 6 FUSE 7 FUSE 8 FUSE 9 INSTRUMENT CLUSTER LEFT FRONT FUSE BOX LEFT LUGGAGE COMPARTMENT LIGHT LEFT REAR SEAT ADJUSTMENT OUTPUT CONTROL UNIT OUTPUT TERM 30 2 OUTPUT TERM 30-1 PASM CONTROL UNIT PCM PDCC CONTROL UNIT POWER LIFTGATE CONTROL UNIT PREMIUM RADIO RADIO RAIN SENSOR REAL TOP VIEW CONTROL UNIT REAR A/C OPERATING UNIT REAR BCM REAR DIFFERENTIAL LOCK CONTROL UNIT REAR FUSE BOX (ROW A) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT LUGGAGE COMPARTMENT LIGHT STARTING/CHARGING SYSTEM STEERING COLUMN SWITCHING MODULE STOPWATCH SUBWOOFER TERM 15 TERM 30 TERM 30-2 TERM 31 TERM 50 TO LEFT FRONT FUSE BOX (DIAGRAM 2 OF 7) TO LEFT FRONT FUSE BOX (DIAGRAM 3 OF 7) W/ BURMESTER W/ BOSE W/ MEMORY YEL WIRE

A/C CONTROL UNIT ANTI-DAZZLE INTERIOR MIRROR AUTOMATIC TRANSMISSION BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/RED WIRE BLK/YEL WIRE BRN WIRE CONTROL LINE CTRL LINE DIAGNOSTIC PLUG SOCKET DRIVER SEAT ADJUSTMENT CONTROL UNIT EXCEPT HYBRID FROM MAIN FUSE BOX (DIAGRAM 1 OF 7) FROM MAIN FUSE BOX (DIAGRAM 6 OF 7) FRONT CAMERA CONTROL UNIT FRONT PASSENGER SEAT CONTROL UNIT FUSE 1 FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 2 FUSE 3 FUSE 38 FUSE 39 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 9 GRY/RED WIRE HYBRID EXCEPT HYBRID LEFT FRONT FUSE BOX LEFT HEADLIGHT LUGGAGE COMPARTMENT SOCKET N/A NCA WIRE PARKING ASSISTANCE CONTROL UNIT PCM PDK TRANSMISSION CONTROL UNIT PEDAL VALVE SENSOR RDK CONTROL UNIT REAR A/C OPERATING UNIT REAR BLUETOOTH CHARGING TRAY RED WIRE RED/BLK WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BLUETOOTH CHARGING TRAY RIGHT FRONT CENTER CONSOLE PLUG SOCKET RIGHT FRONT FUSE BOX RIGHT REAR SEAT ADJUSTMENT OUTPUT CONTROL UNIT SELECTOR LEVER CONTROL UNIT STARTER RELAY TERM 30 TERM 31 TO RIGHT FRONT FUSE BOX (DIAGRAM 6 OF 7) TRANSMISSION CONTROL UNIT TV TUNER W/ MEMORY W/O MEMORY WHT WIRE WHT/RED WIRE

ADAPTER 7 RELAY BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE EPB CONTROL UNIT EXCEPT HYBRID FROM LEFT FRONT FUSE BOX (DIAGRAM 2 OF 7) FROM MAIN FUSE BOX (DIAGRAM 1 OF 7) FROM MAIN FUSE BOX (DIAGRAM 6 OF 7) FROM RIGHT FRONT FUSE BOX (DIAGRAM 1 OF 7) FROM RIGHT FRONT FUSE BOX (DIAGRAM 6 OF 7) FUSE 1 FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 2 FUSE 26 FUSE 3 FUSE 37 FUSE 4 FUSE 5 FUSE 53 FUSE 54 FUSE 55 FUSE 56 FUSE 6 FUSE 7 FUSE 8 FUSE 9 GATEWAY CONTROL UNIT GRN/GRY WIRE HIGH VOLTAGE BATTERY SYSTEM MASTER LANE CHANGE ASSISTANT MAXI FUSE N/A PASM COMPRESSOR RELAY PASM CONTROL UNIT PDCC CONTROL UNIT REAR BCM REAR DIFFERENTIAL LOCK CONTROL UNIT REAR FUSE BOX (ROW A) REAR FUSE BOX (ROW B) REAR WINDOW HEATER RELAY REAR WINDOW MODULE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT FUSE BOX SLAVE LANE CHANGE ASSISTANT SPOILER FLAP RELAY TRAILER HITCH CONTROL UNIT TRANSMISSION OIL PUMP RELAY YEL/RED WIRE

3.0L TURBO 3.0L HYBRID 3.6L, 4.8L, 4.8L TURBO AIR BAG CONTROL UNIT AIR QUALITY SENSOR BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE CLUSTER SENSOR DME CONTROL UNIT EXCEPT HYBRID FROM LEFT FRONT FUSE BOX (DIAGRAM 4 OF 7) FRONT BCM FUSE 1 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 25 GRY/BLK WIRE HOMELINK CONTROL UNIT HYBRID EXCEPT HYBRID W/O PASSENGER POWER SEAT W/ PASSENGER POWER SEAT KL 15 RELAY LEFT REAR SEAT BACKREST VENTILATION MOTOR LEFT REAR SEAT CUSHION VENTILATION MOTOR LEFT SEAT BACKREST VENTILATION LEFT SEAT CUSHION VENTILATION LOW TEMPERATURE CIRCUIT WATER PUMP RELAY, A/C CONTROL UNIT MAIN FUSE BOX NCA WIRE PSM CONTROL UNIT REAR BCM RED WIRE RED/BLK WIRE REFRIGERANT PRESSURE SENSOR RIGHT FRONT FUSE BOX RIGHT HEADLIGHT RIGHT REAR SEAT BACKREST VENTILATION MOTOR RIGHT REAR SEAT CUSHION VENTILATION MOTOR RIGHT SEAT BACKREST VENTILATION RIGHT SEAT CUSHION VENTILATION SEAT OCCUPANCY DETECTION CONTROL UNIT STEERING COLUMN SWITCHING MODULE SUN SENSOR TO LEFT FRONT FUSE BOX (DIAGRAM 4 OF 7) TO LEFT FRONT FUSE BOX (DIAGRAM 7 OF 7) TO REAR FUSE BOX (ROW B) (DIAGRAM 5 OF 7) TO RIGHT FRONT FUSE BOX (DIAGRAM 5 OF 7) TRAILER HITCH CONTROL UNIT WHT/BLU WIRE YEL/GRY WIRE YEL/RED WIRE

3.0L HYBRID 3.0L TURBO, 3.6L, 4.8L 4.8L TURBO 4.8L, 4.8L TURBO, 3.0L TURBO AFS CONTROL UNIT BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BRN/BLK WIRE DISCONNECT SERVICE DRIVE POWER ELECTOR DRIVE POWER SELECTOR EXCEPT 4.8L TURBO EXCEPT HYBRID FROM MAIN FUSE BOX (DIAGRAM 1 OF 7) FROM RIGHT FRONT FUSE BOX (DIAGRAM 6 OF 7) FUSE 1 FUSE 17 FUSE 18 FUSE 19 FUSE 2 FUSE 3 FUSE 44 FUSE 45 FUSE 46 GENERATOR GRY/BLU WIRE JUMP START POINT LEFT FRONT FUSE BOX LEFT HEADLIGHT MAXI FUSE 2 MIDI FUSE BOX ORG/WHT WIRE PLENUM PANEL FUSE BOX POWER STEERING PUMP RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT HEADLIGHT SECONDARY AIR PUMP RELAY 1 SOUND SYMPOSER VALVE SPINDLE ACTUATOR STARTER W/ BIXENON W/ XENON, LED
