Porsche Panamera 4 970 facelift (2013-2016) rear differential lock control unit Wiring diagrams
This page contains all the electrical diagrams for the component. rear differential lock control unit, in which he is found in the car Porsche Panamera 4 970 facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
rear differential lock control unit wiring diagram (1 of 5)
BLK/BRN WIRE
CAN DRIVE HIGH
CAN DRIVE LOW
CAN HIGH
CAN LOW
CLUSTER SENSOR
DME CONTROL UNIT (HYBRID)
ELECTRICAL POWER DRIVE (HYBRID)
EPB CONTROL UNIT
FUSE 5
FUSE 8
HIGH VOLTAGE BATTERY SYSTEM
HOT AT ALL TIMES
HOT W/ KL 15 RELAY ENERGIZED
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/RED WIRE
ORG/VIO WIRE
ORG/WHT WIRE
PARK ASSIST CONTROL UNIT
PARKING HEATER CONTROL UNIT
PASM LEVEL CONTROL UNIT
PEDAL VALUE SENSOR
PORSCHE DYNAMIC CHASSIS CONTROL UNIT
RADIO
REAR DIFFERENTIAL LOCK CONTROL UNIT
REAR FUSE BOX (ROW B)
RED WIRE
RED/YEL WIRE
YEL WIRE
Go to component -> Computer data lines circuit (2 of 3) -> REAR DIFFERENTIAL LOCK CONTROL UNIT
rear differential lock control unit wiring diagram (2 of 5)
ACC CONTROL UNIT RELAY
AIR CONDITIONING RELAY
BLOCKING CAPACITOR GROUND
BLU WIRE
BRN WIRE
CAPACITOR GROUND
CONDENSER BLOCK CIRCUIT
DC/DC CONVERTER 1
DC/DC CONVERTER 2
EXCEPT HYBRID
EXHAUST FLAP VALVE
GATEWAY CONTROL UNIT
HIGH MOUNTED STOP LIGHT
HIGH-VOLT BATTERY SYSTEM
HV CHARGER
LEFT NUMBER PLATE LIGHT
LEFT REAR HEIGHT SENSOR
LEFT REAR LID LIGHT
LEFT TAILLIGHT ASSEMBLY
MAIN FUSE BOX
MASTER LANE CHANGE ASSISTANT
PASM CONTROL UNIT
PDCC CONTROL UNIT
POWER LIFTGATE BUTTON
POWER LIFTGATE CONTROL UNIT
PTC HEATER BATTERY
RDK CONTROL UNIT
REAR BCM
REAR DIFFERENTIAL LOCK CONTROL UNIT
REAR WINDOW HEATED RELAY
REAR WINDOW HEATER RELAY
RIGHT NUMBER PLATE LIGHT
RIGHT REAR BRAKE PAD WEAR INDICATOR
RIGHT TAILLIGHT ASSEMBLY
SLAVE LANE CHANGE ASSISTANT
SPOILER FLAP RELAY
SUPERCHARGER LEVEL CONTROL
SUPPRESSION CAPACITOR
TAILGATE LOCK MOTOR
TERM 85
TRAILER HITCH CONTROL UNIT
TRAILER SOCKET
Go to component -> Ground distribution circuit (6 of 7) -> REAR DIFFERENTIAL LOCK CONTROL UNIT
rear differential lock control unit wiring diagram (3 of 5)
3.6L, 4.8L, 4.8L TURBO
A/C CONTROL UNIT
AFTER-RUN COOLANT PUMP
AMPLIFIER
ASK AMPLIFIER
BACKUP CAMERA CONTROL UNIT
BASE RADIO
BLK/BLU WIRE
BLK/GRN WIRE
BOSE AMPLIFIER
BRN WIRE
DC/DC CONVERTER 1 (W/ START/STOP FUNCTION)
DIAGNOSTICS 1
DIAGNOSTICS 2
DRIVER'S SEAT CONTROL UNIT
EXCEPT HYBRID
EXCEPT HYBRID W/ ASK W/ BASE
FROM DC/DC CONVERTER 1 (DIAGRAM 3 OF 7)
FROM MAIN FUSE BOX (DIAGRAM 1 OF 7)
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 51
FUSE 52
FUSE 53
FUSE 54
FUSE 55
FUSE 6
FUSE 7
FUSE 8
FUSE 9
INSTRUMENT CLUSTER
LEFT FRONT FUSE BOX
LEFT LUGGAGE COMPARTMENT LIGHT
LEFT REAR SEAT ADJUSTMENT OUTPUT CONTROL UNIT
OUTPUT TERM 30 2
OUTPUT TERM 30-1
PASM CONTROL UNIT
PCM
PDCC CONTROL UNIT
POWER LIFTGATE CONTROL UNIT
PREMIUM RADIO
RADIO
RAIN SENSOR
REAL TOP VIEW CONTROL UNIT
REAR A/C OPERATING UNIT
REAR BCM
REAR DIFFERENTIAL LOCK CONTROL UNIT
REAR FUSE BOX (ROW A)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT LUGGAGE COMPARTMENT LIGHT
STARTING/CHARGING SYSTEM
STEERING COLUMN SWITCHING MODULE
STOPWATCH
SUBWOOFER
TERM 15
TERM 30
TERM 30-2
TERM 31
TERM 50
TO LEFT FRONT FUSE BOX (DIAGRAM 2 OF 7)
TO LEFT FRONT FUSE BOX (DIAGRAM 3 OF 7)
W/ BURMESTER W/ BOSE
W/ MEMORY
YEL WIRE
Go to component -> Power distribution circuit (3 of 7) -> REAR DIFFERENTIAL LOCK CONTROL UNIT
rear differential lock control unit wiring diagram (4 of 5)
ADAPTER 7 RELAY
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
EPB CONTROL UNIT
EXCEPT HYBRID
FROM LEFT FRONT FUSE BOX (DIAGRAM 2 OF 7)
FROM MAIN FUSE BOX (DIAGRAM 1 OF 7)
FROM MAIN FUSE BOX (DIAGRAM 6 OF 7)
FROM RIGHT FRONT FUSE BOX (DIAGRAM 1 OF 7)
FROM RIGHT FRONT FUSE BOX (DIAGRAM 6 OF 7)
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 2
FUSE 26
FUSE 3
FUSE 37
FUSE 4
FUSE 5
FUSE 53
FUSE 54
FUSE 55
FUSE 56
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GATEWAY CONTROL UNIT
GRN/GRY WIRE
HIGH VOLTAGE BATTERY SYSTEM
MASTER LANE CHANGE ASSISTANT
MAXI FUSE
N/A
PASM COMPRESSOR RELAY
PASM CONTROL UNIT
PDCC CONTROL UNIT
REAR BCM
REAR DIFFERENTIAL LOCK CONTROL UNIT
REAR FUSE BOX (ROW A)
REAR FUSE BOX (ROW B)
REAR WINDOW HEATER RELAY
REAR WINDOW MODULE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FUSE BOX
SLAVE LANE CHANGE ASSISTANT
SPOILER FLAP RELAY
TRAILER HITCH CONTROL UNIT
TRANSMISSION OIL PUMP RELAY
YEL/RED WIRE
Go to component -> Power distribution circuit (5 of 7) -> REAR DIFFERENTIAL LOCK CONTROL UNIT
rear differential lock control unit wiring diagram (5 of 5)
BATT PWR
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRAKE POSITIVE
BRAKE/
BRN WIRE
BRN/BLK WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
ELECTR BATT
ENG TEMP
ENGINE TEMP
ENGINE TEMP GND
FUSE 10
FUSE 6
FUSE 7
HOT W/
HOT W/ KL 15 RELAY ENERGIZED
IGN
MOTOR A
MOTOR B
MTR A
MTR A BACK
MTR B
MTR B BACK
ORG/BRN WIRE
ORG/RED WIRE
POSITION
POSITION 1 SIG
POSITION 2 SIG
POSITION GND
POSITION SIG 1
POSITION SIG 2
PWR GND
REAR DIFFERENTIAL LOCK ACTUATOR
REAR DIFFERENTIAL LOCK CONTROL UNIT
REAR FUSE BOX (ROW A)
REAR FUSE BOX (ROW B)
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
SENS 1 GND
TEM SENS GND
VIO/GRN WIRE
VIO/YEL WIRE
Go to component -> Rear differential lock circuit -> REAR DIFFERENTIAL LOCK CONTROL UNIT
