Porsche Panamera 4 970 facelift (2013-2016) porsche dynamic chassis control unit Wiring diagram
This page shows the only wiring diagram for the component.porsche dynamic chassis control unit, which is found in the car Porsche Panamera 4 970 facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram porsche dynamic chassis control unit (1 of 1)
BLK/BRN WIRE
CAN DRIVE HIGH
CAN DRIVE LOW
CAN HIGH
CAN LOW
CLUSTER SENSOR
DME CONTROL UNIT (HYBRID)
ELECTRICAL POWER DRIVE (HYBRID)
EPB CONTROL UNIT
FUSE 5
FUSE 8
HIGH VOLTAGE BATTERY SYSTEM
HOT AT ALL TIMES
HOT W/ KL 15 RELAY ENERGIZED
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/RED WIRE
ORG/VIO WIRE
ORG/WHT WIRE
PARK ASSIST CONTROL UNIT
PARKING HEATER CONTROL UNIT
PASM LEVEL CONTROL UNIT
PEDAL VALUE SENSOR
PORSCHE DYNAMIC CHASSIS CONTROL UNIT
RADIO
REAR DIFFERENTIAL LOCK CONTROL UNIT
REAR FUSE BOX (ROW B)
RED WIRE
RED/YEL WIRE
YEL WIRE
Go to component -> Computer data lines circuit (2 of 3) -> PORSCHE DYNAMIC CHASSIS CONTROL UNIT
